TECHNICAL MACHINE SPECIFICATIONS
AC motor
Motor power
Current
Vacuum motor
Abrasive
Machine weight
Orbital Floor Sander
Model SD150
115V/60 Hz.
1.5 HP, 3,460 RPM
Off load 6 A
On load 12 A (average)
Startup 15A
115V/60 Hz - 230W.
15fl" (400 mm) x 4fi" (115 mm)
133 lbs. (60 kg)
Save These Instructions
OPERATING INSTRUCTIONS
COMMERCIAL ORBITAL SANDER
CONGRATULATIONS
YOU HAVE JUST ACQUIRED A HIGH QUALITY SANDER.
PLEASE READ THIS MANUAL CAREFULLY BEFORE
OPERATING YOUR NEW SANDER. KEEP MANUAL ON
HAND FOR FURTHER REFERENCES.
X8800
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Powr-Flite SD150
Summary of Contents for Powr-Flite SD150
- Page 1 Orbital Floor Sander Model SD150 OPERATING INSTRUCTIONS COMMERCIAL ORBITAL SANDER CONGRATULATIONS YOU HAVE JUST ACQUIRED A HIGH QUALITY SANDER. PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATING YOUR NEW SANDER. KEEP MANUAL ON HAND FOR FURTHER REFERENCES. TECHNICAL MACHINE SPECIFICATIONS AC motor 115V/60 Hz.
-
Page 2: Table Of Contents
Failure to adhere to instructions provided can potentially void any warranties. INTRODUCTION Congratulations on your purchase of a Powr-Flite Orbital Sander. Read this entire manual before operating or servicing the sander. Unpacking the Orbital Sander... -
Page 3: Safety Instructions
S A F E T Y I N S T R U C T I O N S Read these instructions carefully before operating or attempting to carry out any service or maintenance procedure on the machine. To reduce the risk of fire, electric shock and personal injury when using electrical tools, the following basic safety precautions should always be taken. -
Page 4: Important Parts Of The Machine
IMPORTANT PARTS OF THE MACHINE Switch The double-bladed switch is located in the condenser box beside the motor. When the switch is pushed to the left the motor is off. The motor starts when the switch is pressed to the right. Fig. -
Page 5: Machine Set-Up
MACHINE SET-UP Dust bag The dust bag must be placed at the suction tube outlet and hung from the machine handle. Fig. 5 Setting up the handle Loosen the lever. Push the handle tube in as far as possible. Adjust the lever. Fig. -
Page 6: How To Start The Machine
HOW TO START THE MACHINE Setting-up and leveling the sanding plate Disconnect the sander from the power supply. Place the machine in the position shown in (Fig. 9.) Fig. 9 Fit the sanding plate by matching up the two plate holes with the two hooking pins (Fig. -
Page 7: Connection To Power Supply
HOW TO START THE MACHINE Connection to power supply The sander must be connected to a 115V/60 Hz power supply with grounded plugs. CAUTION! To prevent electrocution keep the machine in a dry place. Do not expose the machine to rain. Use 3-wire (GA 14-3) power cords connected to grounded plugs. -
Page 8: Replacement Of The Lamp
Replacement of the lamp The machine has a light fitted with a PL-9W lamp. To replace it: Remove the front plastic part by gently pressing on its sides (Fig. 15). Fig.15 Replace the lamp with a new one (Fig. 16). Dust suction The machine is equipped with a dustbag. - Page 9 ASSEMBLY DRAWING AND SPARE PARTS LIST ref# part # desc ref# part # desc SD129 CAPACITOR USA 100 MF SD143 DUST BRUSH SD130 CABLE WITH PLUG USA 39.2 SD144 LAMP 9W 115V/60Hz SD131 SPLIT PIN ø 1,5 x 12 SD145 HANDLE ACCESS M 8 SD132 SPRING...
-
Page 10: Assembly Drawing And Spare Parts List
ASSEMBLY DRAWING AND SPARE PARTS LIST... - Page 11 DECLARATION OF CONFORMITY DECLARATlON OF CONFORMlTY QUIDE, S.A. declare under our responsibility that the floor sanding machine model ORBI meets the requires standards of safety and health with respect to the design and manufacture of machinery, according to the below mentioned regulations.
