FLOOR STANDS
ECO8/FS
ECO9/FS
STABILITY BRACKET
STACKING KIT
USER INSTRUCTIONS
Dear Customer
Thank you for purchasing this Lincat product.
With correct use and careful maintenance as described in these instructions,
your Lincat product will give years of trouble free use.
We produce over 400 different items of catering equipment and our range is
constantly being extended and improved. Find out more about Lincat
products from your local distributor or direct from us.
IS332 ECN2992
ECO8/LFS
ECO9/LFS
ECO9/FSBT
SK03
ECO8/SK
ECO9/SK
1
Advertisement
Table of Contents
Summary of Contents for Lincat ECO8/FS
- Page 1 Thank you for purchasing this Lincat product. With correct use and careful maintenance as described in these instructions, your Lincat product will give years of trouble free use. We produce over 400 different items of catering equipment and our range is constantly being extended and improved.
-
Page 2: Table Of Contents
CONTENTS STABILITY BRACKET PACK CHECKLIST ............. 3 FLOOR STAND PACK CHECKLIST..............3 TECHNICAL SPECIFICATION ................ 3 FLOOR STAND INSTALLATION ..............4 FITTING STABILITY BRACKET ..............4 INSTALLATION ....................6 CLEANING....................... 6 MAINTENANCE....................6 STACKING KITs ECO8/SK & ECO9/SK............7 SAFETY INFORMATION................. 7 PACK CHECKLIST .................. -
Page 3: Stability Bracket Pack Checklist
If an item is missing please contact your dealer. • Floor stand • User instructions • Guarantee card TECHNICAL SPECIFICATION Model Height Width Depth Net weight ECO8/FS Floor stand ECO9/FS Floor stand ECO9/FSBT for Baking Trays ECO8/LFS Low floor stand ECO9/LFS Low floor stand IS332 ECN2992... -
Page 4: Floor Stand Installation
FLOOR STAND INSTALLATION The floor stand must be secured to the floor with a stability bracket before fitting the oven on the floor stand. FITTING STABILITY BRACKET Figure 1: Floor Bracket position. • Place the stand on a solid, level surface. •... - Page 5 Figure 1: Fitting oven on stand. IS332 ECN2992...
-
Page 6: Installation
INSTALLATION Position the stand on a solid, level surface. Adjust the feet on the stand so it is level. Unscrew the feet from the bottom of the oven. Place the oven on the stand, lining up the foot holes in the base of the oven with the holes on the top of the stand. -
Page 7: Stacking Kits Eco8/Sk & Eco9/Sk
STACKING KITS ECO8/SK & ECO9/SK SAFETY INFORMATION To prevent injury to yourself or your staff and to avoid damaging the product, please read and follow the safety precautions below before setting up and using the unit: • Remove all plastic coatings and clean the unit before use •... -
Page 8: Installation
INSTALLATION Figure 1: Stacking two ovens Place the stand on a solid, level surface. Adjust the feet on the stand so it is level. Fit the lifting handles to the rear of the top oven as directed in the enclosed fitting kit Unscrew the feet from the bottom of both ovens. -
Page 9: Cleaning
Position top oven on top of stacking kit plinth. Screw feet through holes in stacking kit plinth (detail B) and into oven base. Remove the top row of screws in the back panel of the bottom oven. Fit the stacking kit plinth and top oven on top of bottom oven. 10 Screw the top row of screws back into the oven through the stacking kit plinth. -
Page 10: Service Information
Serial plate details • Serial number Lincat reserve the right to carry out any work under warranty during normal working hours, ie Monday to Friday, 08:30 a.m. – 17:30 p.m. GUARANTEE This unit carries a comprehensive UK twelve-month warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
