Innovation in soft start technology
EGS Series Soft Starter
QUICK START GUIDE
EGS-QSG Series. Version 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EEC EGS Series

  • Page 1 Innovation in soft start technology EGS Series Soft Starter QUICK START GUIDE EGS-QSG Series. Version 01...
  • Page 2 This document may not be reproduced, in full or in part, without written permission. Enquiries about copyright of EEC deliverables should be made to Electrical & Electronic Controls (EEC) Ltd. If, by permission of the copyright owner, any part of this document is quoted, then a statement specifying the original document shall be added to the quotation.
  • Page 3 EGS Series soft starts contain dangerous voltages when connected to the mains supply. Only qualified personnel that have been completely trained and authorised, should carry out installation, operation and maintenance of this equipment.
  • Page 4: Installation

    Means to effect proper air flow through the enclosure Enclosure Ventilation When fitting EEC’S EGS Series into a cabinet, ensure proper heat dissipation. The formula below can help provide approximations of the space required. Note: These would not be required for any NEMA 1 / IP21-41 application.
  • Page 5 Installation (continued) Handling The EGS Series soft starter range comprises 3 frame sizes, with various weights and dimensions. See pages 5-7 for further information. Prior to installing the EGS unit, the installer should carry-out a risk assessment. If considered appropriate, a suitable handling device should be used.
  • Page 6 Installation (continued) Dimensions EGS-017A to EGS-065A Weight 1.97kg [3.75lb] ht1.97kg b) [ ] = inch [4.25] [5.83] [3.54] Fitting 75mm [2.95] Air Flow 75mm [2.95] EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 7 Dimensions EGS-080A to EGS-195A Weight 6kg [13.22lb] [ ] = inch [5.8] [9.3] 100mm [3.93] 100mm [3.93] 100mm [3.93] Air Flow EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 8 Dimensions EGS-242A to EGS-361A Weight 15kg [33.10lb] [ ] = inch [13.1] [8.07] [6.4] [2.4] [6.3] 162.9 125mm [4.92] Air Flow 125mm [4.92] EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 9: Electrical Installation

    These fuses must be fitted externally to the EGS Series chassis to comply with certain standards. It is the responsibility of the installer and system designer/specifier to ensure that the required standards or regulations are not affected by so doing.
  • Page 10: Electrical Connections

    Supply USB Connector Connections (L1, L2, L3) RJ45 connector (Modbus RTU) Control Terminals AC Induction Motor Mains Circuit Wiring Diagram Connections (T1, T2, T3) Protection Switch Gear (Provided by customer) EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 11 Protection Switch Gear (Provided by customer) 1/L1 3/L2 5/L3 2/T1 4/T2 6/T3 For single phase operation the mode of the soft start must be set correctly in the Advanced menu: EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 12: Control Terminal Connections

    Hold Start Ramp Enable Fire Mode In Fire Mode all trips are disabled. Digital Outputs13,14, 21,22 Selectable Functions The outputs may be mapped to Fault or Top-of-Ramp, Auto Reset Pending or Exceeded. EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 13 - EGS-ACU. 2-Wire Control Wiring Diagram 24Vdc K2.2 Stop Note: 110 – 230V Start control supply possible K2.1 with optional control supply modules - EGS- ACU. EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 14: Motor Overload

    Motor Overload The EGS Series provides full motor overload protection, configurable through the user interface. Overload trip settings are determined by the Motor Current setting and the Trip Class setting. Trip class choices are Class 10, Class 20, and Class 30. The EGS Series soft starters are protected using full I T motor overload with memory.
  • Page 15 Keypad Guidance Examples All keys active Left & Right keys active Right, Down & Centre keys active Note: A flashing centre button indicates that a menu item may be selected or saved. EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 16 Configuration and Parameters (continued) Local Motor Start Operation - Example Navigation Method Quick Return to Status Screen Auto Application Setup (Centre button to adjust) EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 17 Screen Vibrating Shredder Wood Chipper Compressor 1 = Centrifugal, Reciprocating, Rotary Screw Compressor 2 = Rotary Vane, Scroll Pump 1 = Submersible: Centrifugal, Rotodynamic Pump 2 = Positive Displacement: Reciprocating, Rotary EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 18 Rated conditional short-circuit current and type of co-ordination See Short Circuit Protection Tables for rated with associated short circuit protective device (SCPD) conditional short-circuit current and required current rating and characteristics of the associated SCPD EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 19 (normally open) Form B – Single gap break-contact 21, 22 Auxiliary (normally closed) Circuit Resistive load, 250Vac, 2A. Utilisation category, voltage rating, current rating Cosø =0.5, 250Vac, 2A Continued over EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 20 90-40 (40 cycles per hour) 90-30 (30 cycles per hour) EGS-125A EGS-160A 90-20 (20 cycles per hour) EGS-195A 90-10 (10 cycles per hour) EGS-242A – EGS-361A have permanently fitted fans EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 21 M8 Stud EGS-242A ≥ 25mm ≥ 4AWG EGS-302A to ≥ 35mm ≥ 3AWG EGS-361A Protective Earth wire size based on bonding conductor requirements of UL508 Table 6.4 and UL508A Table 15.1. EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 22 Correctly selected semiconductor fuses can provide additional protection against damage to the EGS unit (this is sometimes referred to as type 2 co-ordination). These semiconductor fuses are recommended to provide this increased protection. EGS Series Quick Start User Manual Version 01 - 2020...
  • Page 23 For EGS-017A-N to EGS-195A-N models, a higher duty cycle F-S is possible with optional fan fitted as indicated in Fan option table. For EGS-242A-N to EGS-361A-N models with fans fitted as standard, consult EEC for higher duties. EGS Series Quick Start User Manual...
  • Page 24 Notes EGS Series Quick Start User Manual Version 01 - 2020...
