- Page 1 INSTALLATION GUIDE Mobile Light Series For help, call 877-BIG FANS or visit www.bigassfans.com/support...
- Page 2 Suitable for damp locations. Not for use in dwellings. The Big Ass Fans product warranty will not cover equipment damage or failure caused by improper installation. This product contains high intensity LED devices. The fixture should be positioned so that prolonged staring into the luminaire at a distance closer than 6 ft (1.8 m) is not expected.
- Page 3 HARDWARE e. (4) Carriage bolt washer a. (2) 1/2-13 x 3-1/2” hex head cap screw b. (2) 1/2” hex nut f. (10) 3/8-16 x 1” bolt* g. (12) 3/8” washer* c. (2) Angle adjustment knob h. (10) 3/8”-16 nylock nut* d.
- Page 4 3. Bolt fixture to bracket assembly Loosen the two-quarter turn screws and open the cover. Remove and discard the nylon locking nuts to remove the eyebolts. Position the fixture in the bracket as shown. Reattach the eyebolts using the provided nuts. Eyebolt Bracket Fixture...
- Page 5 If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by Big Ass Fans or a Big Ass Fans service agent or a similar qualified person in order to avoid a hazard. For assistance, please contact Customer Service.
- Page 6 For questions about your product, please contact a customer service representative at 877-BIG-FANS (877-244-3267) or visit www.bigassfans.com/support Customers outside the United States For questions about your product or customer service inquiries, please contact your local Big Ass Fans representative or visit www.bigassfans.com/support...
- Page 8 HBL-INST-103-ENG-01 REV E 10/18/2018 2251 Innovation Drive, Lexington, KY 40511 1 (877) BIG-FANS | WWW.BIGASSFANS.COM...
