Marvel 407 Quick Start Manual

Tail rotor hub & blade assembly balance bell helicopter

Advertisement











nd
40 North 2
 Street
Stroudsburg, PA 18360 USA
570­421­6221

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 407 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marvel 407

  • Page 1                     40 North 2  Street  Stroudsburg, PA 18360 USA  570­421­6221 ...
  • Page 2 Tail Rotor Hub & Blade Assembly Balance  Bell Helicopter Model 407 Typical               Balance Equipment    Balance Indicator and Rotor Mount      1 ea.  7HEL104    Kit – Tail Rotor Balance    Note: The 7HEL104 Kit supplies all balance equipment required for this rotor. Due  to multipurpose application, balance equipment for other model helicopters  may include one or more of its individual parts. Refer to the installation  illustration for identification.               Preparation    1.  Select a draft free area. Provide a flat top bench and hoist equipment or  other means of suspension.  2.  Provide two standard 2” x 4” wood blocks approximately 6” long. Place on  edge approximately 3 ½” apart on bench top.  3.  Remove 3165 Arbor from kit case, remove stored adapters from arbor shaft  and stand upright in bore of case block.    4.  Clean oil from indicator area, if present, and depress indicator collar, ...
  • Page 3 Install posts in outermost threaded bores of base.  3.  Place 3832 Adapter, recessed end downward, over hub extension of base.  4.  Position tail rotor assembly outboard side upward (hub data plates upward,  pitch horn fork sections upward), and engage trunnion bore with adapter  cone section.  5.  Position (rotate) tail rotor assembly to align pitch horn ends with 2939  Posts and insert small diameter of posts into bolt bore of pitch horns to set  and maintain blade pitch.  6.  Install 2533 Bushing, knurled end upward, on 3165 Arbor from lower end,  position near top end of arbor shaft and temporarily secure with set screw.  7.  Install 2586 Plate on arbor from lower end and position against bushing.  8.  Install 3822 Cone, large end upward, on arbor from lower end and position  to align its top surface at arbor scale sensitivity setting indicated by the  installation illustration. Secure by moderately tightening both set screws.   9.  Insert arbor downward thru trunnion, adapter and base. Seat cone firmly  into trunnion bore, maintain positive downward clamping pressure and  secure by moderately tightening both set screws in hub of base.   10. Lower plate and bushing on arbor to seat firmly on rotor yoke and secure  by moderately tightening set screws in bushing. Maintain engagement of  posts with pitch horns.  11. Suspend assembly to clear work support. Stabilize movements and  observe balance condition as indicated by exposure of black disc in top  surface of arbor shaft. Check to insure indications are not affected by  interferences, air drafts, or movement of nearby personnel.  12. Refer to applicable helicopter maintenance manual for balance tolerance,  method of correction or other assembly requirements.        3                              The Marvel Manufacturing Company copyright 2017 ...
  • Page 4   4                              The Marvel Manufacturing Company copyright 2017 ...
