Part names

Part names
Power cable Power cable
Flush mount Flush mount
3-Axis gimbal 3-Axis gimbal
Lens Lens
Safty wire Safty wire
Dome cover Dome cover
Bubble dome Bubble dome
BOTTOM VIEW
Coupler board Coupler board
6
BOTTOM VIEW
Joystick for Joystick for
Zoom / Focus control Zoom / Focus control
RTx Status Indicator RTx Status Indicator
Reset Button
Micro SD Card slot Micro SD Card slot
Power supply connector Power supply connector
Ethernet connector Ethernet connector
Reset Button
(Default)
