Assembly instructions: Freestanding cabinet
Please take the time to read the instructions. Please do not just proceed by looking at the
pictures alone! It is noticeable to you when you set it up. Thank you
For safety and practical reasons, please note the following:
To avoid damage to the material and accidents, the cabinet should be assembled by two
people.
An important piece of information about the custom-made cabinet with depths of less than
44 cm.
Usually, our closet does not need to be wall-mounted as it is quite heavy and stable.
In certain cases, instead, due to the reduction in depth and high height, it is mandatory to
mount them on the wall. The person who performed the installation must attach it to the
wall before installing the door to avoid the risk of falling forward.
Please open the packages in the order listed. This will help you to avoid assembly
difficulties!
When opening the package of metal parts, small parts and fittings, please ensure that no
part is lost, since the parts are counted exactly and are only available in the number
required for assembly.
If you also ordered LED lights, please note the following before setting up:
The horizontal sensor LED bar with motion detector (see video) is mounted under the
wardrobe cover at the top (inside the cabinet). Use the two supplied screws for this.
The vertical LED bar, in the dividing side panel (see video), is installed in the inner cheek in
which the milling is provided for this at the factory. In our video you can see how to
assembly it with the wardrobe dividing side panel hole already prepared; however, it is
much easier to install on a cupboard dividing side lying on the floor or on the table. Be sure
to start at the top, 2.5 cm below the end of the dividing side panel, on which the cupboard
top cover will be attached later, when you insert the vertical LED bar in the horizontal
wardrobe dividing side panel. Since the same LED lengths are used for different cupboard
heights, it can happen that a small part of the lower, vertical LED bar is covered by the
wardrobe base.
Horizontal LED strips: For the power cable, a hole should be drilled into the wardrobe top
