TigerStop TigerFence SLR Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2017 TigerStop, LLC
®
TigerFence SLR
1
February 2017 Mk1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TigerFence SLR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TigerStop TigerFence SLR

  • Page 1 2017 TigerStop, LLC ® TigerFence SLR February 2017 Mk1...
  • Page 2 Serial Number Controller Mounting Controller Stand Brackets Controller Cable Power Cable Solenoid Cable Pneumatic Regulator Solenoid Valve Tubing Quick Reference Nut Pack Nut Pack Cards Pneumatic Drilling Template...
  • Page 3 IMPORTANT SAFETY INFORMATION. READ ALL WARNINGS BEFORE OPERATING THIS PRODUCT. WARNING: Installation of your TigerStop Product must be done by a person trained in the safe design and installation of automation products, and in the safe operation of power equipment. Ensure...
  • Page 4 IMPORTANT SAFETY INFORMATION. READ ALL WARNINGS BEFORE OPERATING THIS PRODUCT. Keep the work area clean and well lighted to avoid accidental injury. Do not use TigerStop machines in a dangerous environment. Using power tools in damp or wet locations or in rain can cause shock or electrocution.

  • Page 5: Table Of Contents

    Table of Contents Table of Contents Installation Requirements....................6 TigerFence SLR Installation.....................7 Enable Code......................14 First Power Up......................15 Find the End Limits Auto Detect Calibrate Set Kerf Set Units Set Optimizer Settings Basic TigerFence Functions..................20 Entering Decimals Entering Fractions Calculator Mode Increment...

  • Page 6: Installation Requirements

    20 Amps 240 VAC 20 Amps TigerFence SLR must have a dedicated circuit. No other equipment should be on the same circuit. WARNING! Do NOT use a high leg delta circuit to power TigerFence SLR. If you are not sure what kind of circuit you are using, STOP! Have a qualified electrician confirm the main power circuit.

  • Page 7: Tigerfence Slr Installation

    TigerFence SLR Installation TigerFence SLR Installation WARNING! Read all instructions before performing installation! NEVER power up system while motor box is open! ALWAYS lock out/tag out TigerStop machinery before installing! WARNING! TigerFence SLR Anatomy Controller Cylinder Bracket Motor Box TigerFence...
  • Page 8 3. Attach TigerFence SLR to the table using the spacers and supplied hardware. Note: Ensure the TigerFence SLR is flush with the saw table top. Lock Washer Mount Fence to TigerFence Fence Square Adjustment Screws...
  • Page 9 4. Attach your existing ripping fence to the TigerFence SLR fence bracket. Note: You may need to drill the existing rip fence. Mount Anti-Kickback Teeth Control Drill & Tap...
  • Page 10 Connect to anti kick back lever Plumb Pneumatics Anti Kick Back Cylinder Solenoid Valve Regulator Main Air Input...
  • Page 11 Install Controller Stand...
  • Page 12 Note: Attach the controller stand anywhere that is convenient for the machine operator. Set Range of Movement by Adjusting End Sensors End Sensors Loosen & Move...
  • Page 13 Final Connections Final Connections White End (Motor Box) Black End (Controller) Controller Cable 15 Pin Controller TigerStop Motor Box Solenoid Cable 6 Pin Solenoid TigerStop Motor Box Black TigerStop Power Cable Power Cable Power Outlet TigerStop Motor Box...

  • Page 14: Enable Code

    The enable code notifies TigerStop, LLC when your new TigerFence is about to be put into service. This lets us start the warranty on the exact day you turn it on. The enable code also allows TigerStop to turn on your TigerStop Dynamic Optimization upgrade.

  • Page 15: First Power Up

    Home Routine. 2. When movement stops, TigerStop will display the Ready Screen. The Ready Screen is the starting point for all TigerStop functions. Let’s take a look at the screen, line by line. Line 1 displays the “heartbeat”. The heartbeat is a line that rotates and lets you know that TigerFence is functioning normally.

  • Page 16: Find The End Limits

    Line 3 shows the next position of TigerFence. This is where user input is shown. Line 4 displays the soft key prompts. These prompts tell you what the soft key button below it does. These can change when you access different screens.

  • Page 17: Set Kerf

    Set Kerf If the tool you have installed TigerStop to is a cutting tool, you will need to set the Kerf setting. The kerf is the measure of how much material is destroyed by the saw blade during a cut.

  • Page 18: Set Units

    Set Units TigerFence can display its position in inches or metric. If you do not wish to change the units, skip this step. 1. From the Ready Screen, press the [Show] soft key to show the menu options. 2. Press the [Menu] soft key to display the Menu Select screen. 3.
  • Page 19 Opt Time setting. The Optimizer Time setting sets the amount of time the TigerStop Optimizer has to find a solution. If it takes longer than this time, TigerStop will use the best found optimized solution.

  • Page 20: Basic Tigerfence Functions

    Basic TigerFence Functions Basic TigerFence Functions Manual Movement To manually move TigerFence to a position, you must enter the length you want TigerFence to go to. This length can be entered as a decimal or a fractional value. Entering Decimals 1.

  • Page 21: Increment

    Just like a normal calculator, you can use the math function keys to enter math problems. Example: I want to add 12 inches to 30 inches. Press [1] [2] [+] [3] [0] The answer will appear in the ‘Next’ field. START 2.

  • Page 22: Preset

    3. A new set of options have appeared. Press the [Incr] soft key to access the Increment menu. 4. Enter the size you want to increment and press For this example, I am going to use an increment of 2 inches. 5.

  • Page 23: Quick Calibration

    6. The PreSet value is now set. STOP 7. Press to go back to the Ready Screen. Using the PreSet 1. Start at the Ready Screen. 2. Press the [PrSet] soft key to access the PreSet menu. START 3. Enter the PreSet number you wish to use and press 4.

  • Page 24: Working With Part Lists

    A set point list will tell TigerFence to act as a stop. It will treat each length you enter as an absolute value from your zero point. Set point lists can be optimized if you have the TigerStop Dynamic Optimizing upgrade.
  • Page 25 Note: You can also download all the parts straight from your design file. Downloading is a faster way of importing parts for use with the TigerStop Optimizer. Press the [Done] soft key when all parts are entered.

  • Page 27: Maintenance Schedule

    Maintenance Schedule Maintenance Schedule Record the following settings for future reference. Serial Number: Drive Test Results Min Limit: MxP = Max Limit: MxN = Scale: P+ = Kerf: P- = Lash: Daily 1. Clean all dirt and debris from drive areas. 2.
  • Page 28 Maintenance Log Maintenance Log Date Maintenance Performed Drive Test Results...
  • Page 29 Maintenance Log Maintenance Log Date Maintenance Performed Drive Test Results...
  • Page 32 FIND US ONLINE AT www.tigerstop.com 12909 NE 95th Stree Vancouver, WA 98682-2426 1.360.254.0661 sales@tigerstop.com TigerStop B.V. Holland 31 546 575 171 info@tigerstop.nl...
