Thank you for deciding to purchase a quality AgriQuip Hydrasplitter.
Please follow the following connection, operation, maintenance and
safety instructions to get the best use of your splitter.
This operating manual containers basic instructions that must be
followed during connection, operation and maintenance. Read this
manual before attempting to operate the Hydrasplitter.
Keep this manual handy at all times
Length
Width
Height
Maximum Jaw Opening
Hydraulic Supply Requirements
- 1 -
Introduction
TPL Specifications
1700 mm
880 mm
540 mm
400 mm
30 L/min
Advertisement
Table of Contents
Summary of Contents for Agria Hydrasplitter TPL
- Page 1 - 1 - Introduction Thank you for deciding to purchase a quality AgriQuip Hydrasplitter. Please follow the following connection, operation, maintenance and safety instructions to get the best use of your splitter. This operating manual containers basic instructions that must be followed during connection, operation and maintenance.
- Page 2 - 2 - VTL Specifications Depth 900 mm Width 1200 mm Height 1650 mm Maximum Jaw Opening 400 mm Hydraulic Supply Requirements 30 L/min...
-
Page 3: Qualification And Training Of Personnel
- 3 - Qualification and Training of Personnel The Hydrasplitter must only be used, serviced and maintained by personnel that are familiar with the machine and are informed about its dangers. The owner is responsible for the competence and supervision of the operator. -
Page 4: Operation
- 4 - Connection The Hydrasplitter is designed to mount to the three point linkage of a tractor. To install the machine onto your tractor: 1) Place the splitter on a firm and stable platform at a minimum of 300mm high. 2) Remove the lynch pins from the lower two link pins and remove the top link pin and set aside. -
Page 5: Safety Precautions
- 5 - Safety Precautions Before starting work, familiarise yourself with all equipment, operating parts and their functions – during operation there maybe no time to do this Avoid loosely fitting clothes Check the immediate area before moving and before starting operation for animals, children and bystanders. -
Page 6: Maintenance
- 6 - Maintenance Removing Trapped Air from the Hydraulic System (Bleeding) After connecting the splitter for the first time and after work has been performed on the hydraulic rams or valves, the Hydrasplitter will have to have any trapped air removed before putting it into service. This is known as “bleeding”... -
Page 7: Storage & Protection
- 7 - Lubrication Points TPL Lubrication Points VTL Lubrication Points Storage & Protection So that the Hydrasplitter continues to function efficiently and has a longer working life, follow these precautions: Do not twist or kink the hoses; Empty before storing;... -
Page 8: Parts Replacement
- 8 - Parts Replacement The owner must ensure that all replacement of parts and assembly work is carried out by AgriQuip authorised personnel. Conversion of, or changes to, the machine will only be permitted after consultation with AgriQuip. AgriQuip original spare parts and accessories prolong the useful life of the Hydrasplitter, ensure correct and efficient operator and do not compromise safety. -
Page 9: Troubleshooting
- 9 - Trouble Shooting PROBLEM CAUSE SOLUTION Change so that the male Quick couplers will not Fittings of different types and female fittings are the mate same type Hydraulic hoses restricted Clear or change the hoses Insufficient hydraulic Adjust the relief valve using a pressure gauge. -
Page 10: Warranty
- 10 - Warranty The Agriquip Hydrasplitter is covered by a comprehensive warranty against faulty materials and workmanship provided that: The machine is operated in normal use as set out in this Owner’s Manual; The machine is correctly serviced and maintained as specified in this manual;... - Page 11 - 11 - TPL Parts Manual Item Part No. Description 49765 Main frame 49766 Rod end pin 49767 Ram seal kit 49772 49768 Top link pin 49771 Valve assembly 49769 Valve seal kit 49770 Ram pin...
- Page 12 - 12 - VTL Parts Manual Item Part No. Description Main frame 49766 Rod end pin 49767 Ram seal kit 49772 49768 Top link pin 49771 Valve assembly 49769 Valve seal kit 49770 Ram pin...
- Page 14 PLEASE NOTE: HYD. VALVE KITS & CARTRIDGES BEFORE REMOVING VALVE SPOOL OR SPOOL SLEEVE REMOVE DETENT ADJUSTING CARTRIDGE, DETENT PISTON AND STEEL BALL. INSERT SPOOL AND ITEM DESCRIPTION SPOOL SLEEVE BEFORE INSERTING STEEL BALL. DETENT SLEEVE PRESSURE RELEASE DETENT WASHER This feature provides a pressure release detent for the spool "out"...
- Page 15 - 15 - Notes _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________ _____________________________________________________...
