Cocraft MRC-982 Manual

Gas Torch
Art.no 41-1415 Model MRC-982
Please read the entire instruction manual before using the product and then save it for future
reference. We reserve the right for any errors in text or images and any necessary changes
made to technical data. In the event of technical problems or other queries, please contact
our Customer Services.

Safety

Warning
Keep the torch out of the reach of children.
Never store the torch at temperatures above 40 °C. Never leave the torch in
direct sunlight or in places which could reach high temperatures.
The torch must only be used in well-ventilated areas and well away from
combustible materials and liquids. Caution!
• Do not use the torch as a cigarette lighter.
• Caution: Contains extremely flammable gas under pressure.
• Only refill with butane gas.
• Avoid breathing the fumes from soldering or other heating projects. Ensure that the working
area is well ventilated.
• The flame of the torch is very hot and can burn you; make sure to protect your hands and
face. Bear in mind that the flame can be difficult to see.
• Hold the torch upright, the flame could go out if the torch is used in other positions.
• Allow the torch to cool completely before refuelling it.
• The torch must not be modified or disassembled.
• Do not pierce the gas cylinder and do not throw it into the fire even if it is empty.
• Light the torch with the nozzle pointing away from your face and hands.
• Caution: Bear in mind that in certain situations the butane flame is barely visible.
• Do not use the torch if it is damaged.
• Only refill the torch in a well-ventilated area, free from naked flames, sparks and other persons.
Do not smoke whilst refilling the torch.
• Read the instructions on the gas cartridge before refilling the torch.
• Always have a fire extinguisher close by when using the torch.
• Never try to repair the torch.
• Only use the torch in clean environments, away from combustible materials.
• Do not aim the flame at any persons or flammable materials.
• Allow the torch to cool down after use. Make sure that the torch is switched off and cool
before putting it away for storage.
• Store the torch vertical.
• Make sure that the safety lock returns to its original position after use.
• Keep the torch away from grease and grime. Be careful not to drop the torch as this may
cause it to malfunction.
• Caution: The flame guard can be very hot after use.
• In case of a gas leak (smell of gas), take the torch outside to a well-ventilated place where
the leak can be checked.
• Never check a gas leak using a naked flame, only using a leak detection spray.
• Never leave a lighted gas torch unattended.
GREAT BRITAIN • CUSTOMER SERVICE tel. 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ

Product description

1. Baseplate (removable)
4
2. Continuous flame switch
3. Flame guard
4. Flame width adjuster
5. Ignition button
3
6. Ignition button safety lock
7. Flame length adjuster 2
8. Filler valve (not in view,
on bottom of torch)
1

Getting started

Refilling gas

• Check that the filler valve does not leak before refilling the torch.
• Only use a high quality butane.
1. Shake the gas canister a few times to warm the fuel up.
2. Set the flame adjuster (7) to the [ − ] position.
3. Turn the torch and the gas canister upside down and insert
the nozzle of the gas canister into the filler valve (8).
4. Stand the torch on its base and leave it for at least 2 minutes
for the gas to stabilise before use.

Operating instructions

Igniting the torch

1. Set the flame adjuster to the [ + ] position.
2. Slide the safety lock (6) down until it 3. Press the ignition button (5) to light
clicks into the bottom setting. the gas.
• Note: For safety reasons, the ignition button cannot be pressed unless the safety lock is off.
• Caution: Never leave the torch unattended after the safety lock has been taken off.
To put the safety lock back on, the ignition button must be depressed, the safety lock
will then return to its original position.

Setting the flame

1. Hold the ignition button down after ignition.
2. Adjust the length of the flame by sliding the adjuster towards:
- [ + ] to increase the length of the flame.
- [ − ] to decrease the length of the flame.
For best results the flame should be 10−25 mm in length.
If the flame is too long it will be unstable and the torch will use more gas than necessary.
3. The width of the flame can be adjusted by sliding the air controller (4) forwards.
If the adjuster is released it will spring back to its original position.
Note:
• The width adjuster (air controller) should not be used when igniting the torch.
5
• When used at high altitudes the torch may experience problems working with the flame
length adjuster set to maximum [ + ]. For best results it is recommended that the adjuster
is set half way between [ + ] and [ − ].
7

Switching off

6
The flame will extinguish when the ignition button is released.

Continuous flame

Caution:
Be very careful when using the gas torch in continuous mode because the flame will stay lit
8
until the switch (2) is pushed down by hand.
1. Depress the ignition button and
slide the continuous flame switch (2)
upwards.
3. Slide the continuous flame switch down and
the flame will go out.

Care and maintenance

Clean the exterior of the product using a lightly moistened cloth. Use only mild cleaning agents,
never solvents or corrosive chemicals.

Responsible disposal

This symbol indicates that this product should not be disposed of with general
household waste. This applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards caused by incorrect waste
disposal, the product must be handed in for recycling so that the material can
be disposed of in a responsible manner. When recycling your product, take it to
your local collection facility or contact the place of purchase. They will ensure
that the product is disposed of in an environmentally sound manner.

Specifications

28 ml
Gas canister volume
Fuel Butane gas (sold separately)
Fuel consumption 50.9 g/h (0.7 kW)
Rated burn time 90–120 min
Height 7.5 cm
Weight 260 g
2. Release the ignition button and
the flame will continue to burn.
