Summary of Contents for OTFRID Solar Street Light Series
- Page 1 Solar Street Lights Manual. 20W – 60W www.otfridsolar.com Email: otfridsolar@gmail.com Telephone: +86-13210031120/ +86-15610015175. No. 135, Tianfeng South Road, Chengyan District, Shandong Province, China.
-
Page 2: Table Of Contents
Contents. 1. Welcome to your new Otfrid Solar Street Light (20W – 60W)....3 2. WARNING AND SAFETY INSTRUCTIONS.......... 3 3. Operating and Storage Temperature............ 4 4. Modification..................4 5. User Manual..................4 Introduction....................4 6. -
Page 3: Welcome To Your New Otfrid Solar Street Light (20W - 60W)
1. Welcome to your new Otfrid Solar Street Light (20W – 60W). At Otfrid Solar we offer a large selection of Solar Street Lights, ranging from 20 to 60 watts of available power output. Our multiple installation feature enables users to install our products with minimum effort. -
Page 4: Operating And Storage Temperature
In areas that are short of sunlight or experience a steady duration of rain, Otfrid Solar Street Light units may only work for a short while... - Page 5 Otfrid Solar Street Light series work at dim mode when humans are not around and it will increase light output immediately when motion is detected. The SMART lighting will extend the productivity of the battery and the light.
-
Page 6: Part Description
6. Part Description. Name Brief Function Solar Cells Energy Generation Connecting Bracket Fixed main body and lamp head Fixing Screws Connector of bracket and main body Movement Sensor Motion Detection Fastening Bolts Fasten the shaft to the main body LED Nichia Illumination... -
Page 7: Packaging
7. Packaging. Please open the package and corroborate that all parts were received prior to installation. -
Page 8: Installation Guide
2. Take out the main body and the bracket. Attach the bracket to the main body. (Refer to figure 1). 3. Attach the bracket and the main body to the pole (Refer to figure 2). 4. Rotate your Otfrid Solar Street Light as is shown in figure 3. -
Page 9: Multiple Installation Opportunity
Multiple Installation Opportunity:... -
Page 10: Disposal
9. Disposal. At Otfrid Solar we care about the environment. Hence, our products are made of recyclable high-performance materials and all components are ROHS (Restriction of Hazardous Substances) compliant. Do not dispose the appliances with the normal household waste at the end of their life, deliver them to an official collection point for recycling.
