Summary of Contents for Cab Technology ER1
- Page 1 Operator's Manual ER1 / ER2 / ER3 External Rewinder Made in Germany...
-
Page 2: Table Of Contents
Germany France Asia cab Produkttechnik cab technologies s.a.r.l. cab Technology Inc. cab Technology Co., Ltd. GmbH & Co KG F-67350 Niedermodern Tyngsboro MA, 01879 Junghe, Taipei, Taiwan Téléphone +33 388 722 501 Phone +1 978 649 0293... -
Page 3: Introduction
Introduction Notes Important information and instructions are designated as follows: Danger! Draws attention to an exceptionally great, imminent danger to your health or life due to hazardous voltages. Danger! Draws attention to a danger with high risk which, if not avoided, may result in death or serious injury. Warning! Draws attention to a danger with medium risk which, if not avoided, may result in death or serious injury. -
Page 4: Safety Instructions
Introduction Safety Instructions Caution! Risk of injury by rotating parts! During operation, rotating parts are freely accessible. Ensure that people‘s clothing, hair, jewelry etc. do not come into contact with the exposed rotating parts. Attention! Risk of damage ! ... -
Page 5: Product Description
Product Description Function The External Rewinders ER1, ER2 and ER3 are peripheral devices for A+ Series printers to rewind the material after printing. The rewinder is powered and controlled directly by the peripheral port of the printer. The rewinder operates just then if the printer is carrying out a paper feed. -
Page 6: Installation
Installation Unpacking Check rewinder for damage which may have occurred during transport. Check delivery for completeness. Contents of delivery: • External Rewinder • 2 Adapters • Plate • Clamp • Operator's Manual Note! Please keep the original packaging in case the printer must be returned. Attention! The device and printing materials will be damaged by moisture and wetness. -
Page 7: Operation
Operation Setting the Rewind Direction Attention! Risk of damage ! Do not change the rewinding direction, when the rewind axle is turning. Set the switch (1) to the intended rewind direction. Rewinding with labels inside Rewinding with labels outside Figure 3 Setting the rewind direction Rewinding directly onto the Rewind Axle... -
Page 8: Rewinding Onto 76 Mm Cardboard Core
Operation Rewinding onto 76 mm Cardboard Core Figure 5 Rewinding onto 76 mm cardboard core Note! Use a cardboard core which is about 1 mm wider than the label strip. 1. Remove the spring from the rewind axle 4.2 on page 7. 2. -
Page 9: Rewinding Onto 40 Mm Cardboard Core
Operation Rewinding onto 40 mm Cardboard Core Figure 6 Rewinding onto 40 mm cardboard core Note! Use a cardboard core which is about 1 mm wider than the label strip. 1. Mount the spring (2) with the screws (3) to the rewind axle (4). 2. -
Page 10: Reference To The Eu Declaration Of Conformity
Reference to the EU Declaration of Conformity The External Rewinders ER1, ER2 and ER3 comply with the relevant fundamental regulations of the EU Rules for Safety and Health: • Directive 2014/30/EU relating to electromagnetic compatibility • Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic...
