Smart Node
Touch Switches
Model: TS.2S (NL)
Product Guidance
Page 1 of 17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Touch Switches TS.2S NL and is the answer not in the manual?

Questions and answers

Summary of Contents for Smart Node Touch Switches TS.2S NL

  • Page 1 Smart Node Touch Switches Model: TS.2S (NL) Product Guidance Page 1 of 17...

  • Page 2: Table Of Contents

    Table of Contents Table of contents ………………………………………….……………..………… 2 1.About Touch Switches…..…………………………….……………..………….. 3 2. Smart Node Touch Switch TS.2S (NL) ………………….…………..….……. 4 3. Basic Load explanation…….…………………………………………..….…. 5 3.1 Power Supply…………………………………………………………… 5 3.2 Front-End Touch Board………………………….…………………….. 6 4. Installation Guide…………………………………………………………..… 8 4.1 Power Supply Installation………….………………………………..8 4.2 Touch Board with the power supply ….………….……………….….

  • Page 3: About Touch Switches

    This customization is only done on a prior order to the company. Smart Node Touch Switches are capable of regulating multiple loads from a single regulator present. This is a very unique feature of the Smart Node. Smart Node has 8 different modules in Touch Switches: TS.8S1R, TS.8S, TS.4S1R, TS.4S, TS.2S (NL), TS.2S (HL), TS.1C and TS.1B.

  • Page 4: Smart Node Touch Switch Ts.2S (Nl)

    2. Smart Node Touch Switch TS.2S (NL) Smart Node Touch Switch TS.2S (NL) can connect up to two loads. You can turn on/off and lock the appliances connected to it. The two loads are of the type regular load. The combination of the load possible with TS.2S (NL) is described in the further sections.

  • Page 5: Basic Load Explanation

    3. Basic Load explanation This section covers explanation about different types of load in TS.2S (NL). The Touch Switches consists of a Touch Board and a power supply module. These two parts are connected by a connector. 3.1 Power Supply The front view of the power supply module of TS.2S (NL) is shown below: Here Ph indicates Phase (Live wire) input, N indicates Neutral input and HP indicates Heavy Phase input.

  • Page 6: Front-End Touch Board

    connected to this terminal. A single load with a maximum load capacity of 1500 watt can be connected here. If a light with dimmable or non-dimmable driver is connected to this • terminal, we can only turn on/off that light. We cannot dim the intensity of the light.
  • Page 7 General Technical Specifications Some general technical specifications of TS.2S (NL)module are given below Input Voltage 110 to 240 VAC 50-60Hz Temperature 0 to 70°C Non-condense Minimum Life (per switch) 1,00,000 operations Humidity 20% - 80% RH non-condensing Material of the Touch Board Acrylic Power Consumption 0.6W idle and <3W (On Full Load)

  • Page 8: Installation Guide

    4. Installation Guide Smart Node Touch Switch TS.2S (NL) installation can be divided into two parts: first is the power supply connection with the actual load wires and second is the connection of power supply with the front-end Touch Board. We will go deep into each section below.
  • Page 9 The next wiring diagram gives a basic explanation when a TS.2S (NL) is connected with the loads. Please turn off the power by switching off the MCB for safety purpose. Then remove the front panel of the respective switchboard and open the screws of the switch-plate Identify the loads you wish to insert to Touch Switch.

  • Page 10: Touch Board With The Power Supply

    After successful wiring of the loads with the power supply, we now need to connect this power supply with the front-end Touch Board. Now, we need to fit the Smart Node front-end Touch Board with the Norisys plate. Remove the last layer from the Touch Board and fit it with the back-plate of the Nosisys.

  • Page 11: Operations

    Touch Switches during the night. 2) Remote Smart Node Touch Switches can be operated using our IR remote. The remote provided is universal. The remote layout is as shown below: We can turn on/off any load using this remote. We can also set the fan speed or change the brightness of any dimmable light using this remote.
  • Page 12 Touch Switch during the night using the remote. Single Universal Remote One Smart Node remote can work for multiple Touch Switches. Master Control Using a single button, you can turn on and turn off all the loads on a...
  • Page 13 Page 13 of 17...

  • Page 14: Installation - Special Case

    Smart Node Touch Switches on the other side. The following wiring diagram shows a basic two-way connection. If Smart Node Touch Switches are connected on both sides, then the two- way connection is possible and the wiring diagram will be as follows...
  • Page 15 If traditional switches are connected on the other side, then the two-way connection is possible and the wiring diagram will be as follows Page 15 of 17...

  • Page 16: Declaration

    Private Limited. All rights reserved. Without prior approval of Smart Node Automation, reproduction, transfer, distribution or storage of contents in this document in any form is prohibited. Smart Node Automation operates a policy of ongoing development. Thus, Smart Node Automation reserves the right to make changes or improvements to the products described in this document without prior notice.

  • Page 17: Guarantee And Warranty Period

    Smart Node offers seven years of free repairable warranty from the date of billing of the end client. Smart Node will not be liable in any way towards damage caused to products by following: The guarantee or warranty period is expired.
