OPMID M1201 Quick Start Manual

＃M1201 JIS STD cable type speed sensor set
＃M1202 Genuine speed sensor usable type set
＃M1203 Magnetic proximity sensor set
● If you do not have basic skills and knowledge of
motorcycle maintenance, please do not install.
● When installing, please proceed with manufacturer
service manual for each model. ● Do not improperly
install, modify, or change specifications. ● If any
abnormality is found, stop traveling immediately and
check. ● Specifications are subject to change without
notice.
Please read
The warranty period for this product is 6 months.
before
installation. Please keep the receipt or invoice with the date of
purchase together with this book. If there is a quality
defect due to manufacturing reasons within the
warranty period, please contact your dealer. We will
repair or replace the product after confirming the
defect. However, we will not be liable for any damage
(physical damage, personal damage) other than
repair or replacement of this product. Please note.
NOTE NOTE
To prevent malfunction caused by
Release screen lock
heavy rain, this product always keeps
screen lock. Touch for 3 seconds to
release the lock. It will be locked again
Hold for 3 sec
after 5 minutes of no operation.
Key switch ON
Startup screen
after 4 sec
Startup voltmeter
after 10 sec
Necessary to release screen lock.
Speed
Short
Odo
Short
Trip
Short
Voltmeter
Short
Max. speed
Short
OPM SPEEDOMETER
A compact speedometer equipped with basic functions of speed, odo, trip,
voltmeter, maximum speed record, and 3 LED indicators (speed warning
light, neutral lamp, FI or 2-cycle oil warning).
●Speed︓ ～ 360km/h (~200MPH)
●Odo︓~9999km（~9999mile）
●Trip︓~999.9km（~999.9mile）
●Volt meter︓ 8V ～ 18V
●Display︓７Segｘ4 Green LED
●With Touch sensor (Right front）
●Size︓ W57mm×H29mm×D10mm
●Waterproof cord︓IP66
●Operating voltage︓DC10~16V
* Even if it is connected to AC12V, it will not break,
but it will not operate properly when the frequency is low (low RPM)
Red︓FI or OIL Check
Operating procedure
OPOP scrolls
Enter Initial setting
Keep hold
After 10 seconds have elapsed (or touched), it switches to speedometer
mode.
～ 360km/h
(~200MPH)
Setting of speed alarm
Hold for 3 sec
～ 9999km
(~9999MPH)
～ 999.9km
(~999.9MPH)
Erase the record
Hold for 3 sec
8.0V ～ 18.0V
Erase the record
Hold for 3 sec
Features
Green︓Neutral
to next page
Keep hold
Switching of
Increase or Decrease
Speed
Trip
ITEM
M1201/M1202/M1203
Blue︓Speed alarm
Touch sensor
NOTE NOTE
Touch response is indicated
by the lighting of three LEDs.
Save when
No operation for 10 sec
Increase
+5
Short
－5
Changing value
Reduce
When stopping for 5 seconds,
it automatically switches to
trip (blinking display)
When restart running (or
touched), return to
speedometer.
P1
M1201
190401B
