- Page 1 OC983000TX Holly & Martin® a valued brand of SEI 3pc Ottico Table Set Customer Service 1-800-633-5096 service@hollyandmartin.com Assembly Instruction www.hollyandmartin.com...
- Page 2 OC983000TX 3pc Ottico Table Set Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Carefully study the diagrams below. You may receive extra hardware with your unit. Quantity Quantity Quantity...
- Page 3 Quantity Quantity Quantity Of 24pcs Of 1pc Of 12 pcs Cam-Bolt Allen wrench Wood dowel Quantity Quantity Of 36pcs Of 36 pcs PVC cover for body PVC cover for leg Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
- Page 4 OC983000TX 3pc Ottico Table Set Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page "Please do not over tighten cambolts. Please stop when you feel tight" Insert cam locks (3) into predrilled holes on inside side panel left (B) and inside side...
- Page 5 Insert cam locks (3) into predrilled holes on pre-assembled unit on figure 2. Screw cam bolt (4) into pre-drilled holes on top panel (A). Attach top panel (A) to pre-assembled on figure 2 by inserting wood dowel(6)& cam bolt (4) into corresponding pre-drilled holes until top panel (A) &...
- Page 6 Repeat step 1 to 4 Black White Gray to assemble the other two bookcases. Use black PVC cover (7) to cover holes on black unit. Use white PVC cover (7) to cover holed on white unit, And use gray PVC cover (7) to Figure 5 cover holes on gray unit, Stack the three bookcases by...
- Page 7 Parts Replacement Form Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
