InterMetro Ind. MetroBasix Plus MBA190 Assembly Manual

Hide thumbs

page of 23

/ 23
Bookmarks

Quick Links

Download this manual

FOR

MBX

CARTS

MBA190 - LOCKABLE DRAWER COVER

MBA193 - SECURITY BOX

MBA199 - SECURITY BOX

MBA200 - SIDE STORAGE CABINET (for

MBA214/215 - GLOVE BOX

MBA235 - OXYGEN TANK BRACKET

MBA241 - CATHETER HOLDER

MBA242 - CATHETER HOLDER

MBA243 - CATHETER HOLDER

MBA244 - CATHETER HOLDER

MBA245 - TWO-UNIT SCOPE HOLDER

MBA246 - FOUR-UNIT SCOPE HOLDER

MBA568 - OVERBRIDGE BRACKET

MBA605 - SUCTION UNIT HOLDER

MBA664 - COAT RACK

MBA667 - I. V. POLE

MBC207 - SIDE HANDLE, TUBULAR

MBC210 - RAILING KIT

MBC511 - OVERBRIDGE with HANGER

MBC512 - OVERBRIDGE with HANGER

MBP205 - SIDE ACCESSORY BRACKET

MBP207 - BACK ACCESSORY BRACKET

MBP216 - THREE SIDE BINS

MBP217 - THREE SIDE BINS

MBP230 - SIDE SHELF

MBP250 - SHARPS CONTAINER HOLDER

MBP401 - BREAKAWAY LOCK BAR

MBP402 - BREAKAWAY LOCK BAR

MBP403 - BREAKAWAY LOCK BAR

MBP404 - BREAKAWAY LOCK BAR

MBP408 - BREAKAWAY LOCK BAR

MBP410 - BREAKAWAY LOCK BAR

InterMetro Industries Corporation
