- Page 1 User manual / Assembly instructions Louvered Pergola Type Pinela Version: EN – September 2020...
-
Page 2: Table Of Contents
For this reason the instructions provided only serve as a guideline for installation of the product this manual describes. This manual has been compiled with the utmost care, but Deponti B.V. cannot be held responsible for any errors in this manual or the consequences thereof. Furthermore, all rights are reserved and no part of this manual may be reproduced in any way whatsoever. -
Page 3: Introduction
1. Introduction Congratulations on the purchase of your Acrylshop24 pergola! Before you can start enjoying your pergola it must be assembled properly. This manual provides clear instructions for all the steps you must complete for correct assembly of your Acrylshop24 pergola. We recommend that you take the time to read the entire manual before you begin the assembly. - Page 4 2. Safety precautions and warnings (continued) Adding or removing parts, the use or installation of materials. other than described in this manual, may adversely affect the safety of the pergola and is therefore strongly discouraged! Pay attention and be aware of moving parts. Make sure that all power supply is cut off during the assembly.
-
Page 5: Product Description
3. Product description The Pinela roof is a bioclimatic pergola system which is a rotatable panel system. The Pinela panels can rotate 120⁰ degree. Also it protects from sun, rain and limited snow loads. The panels are connected to a linear actuator and are operated with the remote control by the motor. -
Page 6: Parts Overview
4. Parts Overview 4.1 Terminology Linear Actuator Linear Actuator provides the movement of the bioclimatic pergola pannels. The linear actuator is located on the lateral Integrated gutter. The linear actuator has to be adjust to exact movement. This must be done during to installation. The linear actuators works with 24V power. -
Page 7: Hardware Details
2. Hardware details Freestanding model: Integrated gutter – Pillar connection: a. M8 nut stainless steel b. Washer for M8x60 c. M6 nut stainless steel d. Washer for M6x45 Wall installation Wall bracket – Integrated Gutter connection: NOTE: Wall mounting hardware not included. Choose the correct hardware for your installation situation M8x25mm bolt M4.8x25mm self-drilling screw... - Page 8 Linear Actuator – Linear Actuator Connector: 16mm Segment Linear Actuator Connector– 40x20mm Profile connection: M10x50 hexagonal bolt stainless steel M10 washer stainless steel M10 nut stainless steel 40x20mm Profile – Panel Connection: 8mm Segment page...
-
Page 9: Exploded View
4.3 Exploded view Exploded view integrated Gutter BOM ID Description BOM ID Description 1 M8x60 stay bolt 6 Integrated gutter for Pinela 2 Sealed Nut M8 stainless steel 7 Insulation cover - left 3 Washer M8 stainless steel 8 M6x40 stay bolt... -
Page 10: Delivery Inspection
Exploded view Pillar Two module connector 4.4 Delivery Inspection Always carefully check the delivered items against the accompanying delivery note to ensure that the quantity and quality are correct. Any visible defects must be reported in writing within 7 days of delivery. -
Page 11: Preparation For Assembly
Warranty is void if the Pinela pergola is not assembled and installed in accordance with the instructions. page... -
Page 12: Inspection Of Tools And Accessories
5.2 Inspection of tools and accessories Ø16 page... -
Page 13: Assembly
6. Assembly 6.1 Mounting the wall profile (in case of wall installation) 1. Define the mounting bracket position on the wall. 2. Fasten the brackets to the wall with the correct hardware for your situation. W suggest a minimum size of M12. Place the integrated gutter on the wall mounting bracket page... - Page 14 4. Fasten the wall mounting bracket cover on top and tighten it with a M8x25mm bolt. 5. Fix the self-drilling screw in the integrated gutter and wall mounting bracket. page...
-
Page 15: Pillar And Integrated Gutter Connection
6.2 Pillar and integrated gutter connection 1. Fix the aluminium pillar on both sides of the rear integrated gutter with a M8 and M6 sealed nut . (check below image) NOTE: Lift up the rear frame. Don’t work alone. You may need an extra hand. ... - Page 16 2. Connect the rear integrated gutter and lateral integrated gutter into the position as shown in below image. 3. The linear actuator should be placed on the back side of the lateral integrated gutter which (check below image) 4. Fix the lateral side integrated gutter to the rear integrated gutter with M8 and M6 Sealed Nuts. page...
-
Page 17: Panel Installation
5. Check if the structure is level on all sides. 6.3 Panel installation When you start placing the panels. always start with the first front panel. This first panel has a gasket for perfect insulation and has a clamp. The first panel should connect to the clamp. The clamp is already installed to the lateral side integrated gutter. - Page 18 3. To secure the panels in place install the 1.5x1.5mm sheet (strip profile). 4. The pins of the last 3 panel are shorter than the pins of the middle panels. This is to prevent the pins from hitting the linear actuator. The control box should be placed in the rear integrated gutter.
- Page 19 6. The aluminium profile (20x40mm) must be connect to the panels. This profile allows movement of the actuator to the panels. 7. The housing of the panel pin should be from outside in as in image below. 8. In order to secure the 40x20mm aluminium profile. install the snap ring. The snap ring has to be placed on the groove of the panel pin.
-
Page 20: Perimeter Lightning Installation
9. Secure the actuator to the 40x20mm aluminium profile with the snap ring. 6.4 Perimeter lighting installation 1. Place the perimeter lighting profile on the inside of the integrated gutter. (optional) page... - Page 21 2. The perimeter lighting profile should be installed 6mm down from the top of the integrated gutter. 3. Place the perimeter lighting profile cap to the housing on the perimeter lighting profile. 4. Place the corner piece between the perimeter lighting profile in the corners. page...
- Page 22 5. Install the corner cap on top of the integrated gutter’s joint point. page...
-
Page 23: Programming Instructions
7. Programming Instructions 7.1 Remote Control The Pinela is equipped with an integrated actuator that is operated by remote control. For opening. closing or stopping the panels you can use the respective buttons of the remote control. (see image below). -
Page 24: Programming
7.2 Programming The installation and initial setup procedures are the responsibility of a specialized technician. When the Pinela is installed. check the connection of the drive system with its control box - actuator and also actuator to the 40x20mm aluminium profile. - Page 25 Programming of Actuators / panels Step 1: The actuator has to be connected directly to electric power unit (230VAC/50~60 Hz). Notice that the control unit box will not respond to any transmitter until a transmitter is assigned to communicate with the control unit box receiver. ...
-
Page 26: Faq
8. FAQ REASON HOW TO RESOLVE? The motor is not Check if there is power to the unit control The product powerful box. motor would not The motor has Disconnect the power and wait for 15 start no regular minutes then try to start again. current Check if the product is powered. -
Page 27: Warranty Conditions
11. Warranty conditions Warranty in accordance with the warranty conditions and Deponti’s general terms and conditions. These can be found on the website www.acrylshop24.com. Please review the respective articles indicated under the main titles include in the manual for the details of aforementioned special cases.
