SENSE N
CHRONOTHERMOSTAT TOUCH SCREEN
24
00
06
12
18
IT
SO 06/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SENSE N and is the answer not in the manual?

Questions and answers

Related Manuals for Solaris SENSE N

Summary of Contents for Solaris SENSE N

  • Page 1 SENSE N CHRONOTHERMOSTAT TOUCH SCREEN SO 06/13...

  • Page 2: General Warnings

    DESCRIPTION The clock thermostat digital environment touch screen Sense N allows you to adjust the ambient temperature in heating and cooling in a practical way, it helps to save energy and provides in a simple way to a pleasant room temperature. The minimum settable temperature is + 7 ° C (antifreeze): this allows to protect your heating system from damage by freezing.
  • Page 3 Connect the wires: • NC = normally closed • NC = normally closed • NO = normally open • NO = normally open • COM = common • COM = common Ex. Control dry contact boiler Ex. Zone valve Attach the thermostat to the wall using the supplied Close the casing of the relay with the use of a screws screwdriver...

  • Page 4: Adjusting Date And Time

    ADJUSTING DATE AND TIME 1. Press the button Once again, the flashing year. choose the year With the keys 2. Press Once again, the month flashes. Choose the month With the keys 3. Press the button Once again, the flashing day. choose the day With the keys 4.

  • Page 5: Operating Mode

    OPERATING MODE Press to select one of the following 5 modes: 1. icon on the display indicates an operation mode in which the chronostat always operates at a temperature of comfort chronostat always operates at a temperature of comfort 2. icon displayed on the display indicates a continuous operation at tempera- ture night displayed on the display indicates a continuous operation at tempera- ture night 3.
  • Page 6 3. Press the icon once, the symbol and numbers that indicate the tem- ture night (moon) flash. With the keys choose the temperature night (moon) 4. Press to confirm and exit or wait out the auto- ca after 1 minute (after 15 seconds the display is no longer illuminated) NB: the antifreeze temperature indicated by the symbol NB: the antifreeze temperature indicated by the symbol It is fixed at + 7 °...
  • Page 7 comfort temperature, night temperature, intermediate temperature energy saving. The corresponding symbol appears on the display • to press until the clock will not indicate the time up to which you It intends to maintain the selected temperature • Press the button corresponding to the new desired temperature level ( temp.
  • Page 8 EXAMPLE OF DAILY PROGRAMMING Programming of day 2 (= Tuesday): Temp. Night from 0:00 to 6:00 Temp. Of comfort from 6:00 to 10:30 temp. Economy from 10:30 to 18:00 Temp. Of comfort from 18:00 to 21:30 Night Temp. from 21:30 to 00:00 to access programming Press 3 sec.
  • Page 9 to select the night temperature. to press until the clock displays the time to press desired (6:00) to select comfort temperature. to press until the clock displays the time to press desired (10:30)
  • Page 10 Press to select the energy saving temperature THE. until the clock displays the time to press desired (18:00) THE. to select the comfort temperature to press until the clock displays the time to press desired (21:30)
  • Page 11 to select the night temperature. to press until the clock displays the time to press desired (0:00) The programming of day 2 = Tuesday ended. to continue programming and repeat steps "B" to press to "P" (or press to confirm and exit)
  • Page 12 B • 5/2 PROGRAM: 1. Press and hold the button for about 3 seconds to enter the programming mode, the indicator of the day (top of display) blinks 2. Press until the indicators of 1-5 days (Monday to Friday) flash on the display together 3.
  • Page 13 Days chosen for the program- ming 1 2 3 4 5 1 2 3 4 5 6 7 segment the histogram display flashing segment corresponding to First time Histogram Now flashing PROGRAMMING EXAMPLE 5/2 Programming days 1 to 5 (= Monday to Friday): Temp.
  • Page 14 Press the button until the gods indicators 1-5 days (Monday to Friday) flash together to begin programming of 1-5 days (Monday to to press Friday) to select the night temperature. to press until the clock displays the time to press desired (6:00)
  • Page 15 to select comfort temperature. to press until the clock displays the time to press desired (10:30) Press to select the energy saving temperature THE. until the clock displays the time to press desired (18:00)
  • Page 16 THE. to select the comfort temperature to press until the clock displays the time to press desired (21:30) to select the night temperature. to press until the clock displays the time to press desired (0:00) The programming of 1-5 days (Monday to Friday) is finished.
  • Page 17 to continue programming and repeat steps "B" to press to "P" (or press to confirm and exit) C • WEEKLY PROGRAM: 1. Press and hold the button for about 3 seconds to enter the programming mode, the indicator of the day (top of display) blinks 2.
  • Page 18 4. To save the time program and return to operation mode automated tico, press the button at anytime. Caution: the button Caution: the button It must be pressed only at the end of the procedure programming Days chosen for the program- ming 1 2 3 4 5 6 7 1 2 3 4 5 6 7 segment the histogram display...
  • Page 19 Press the button until the gods indicators 1-7 days (Monday to Sunday) flash together to begin programming of 1-7 days (Monday to to press Sunday) to select the night temperature. to press until the clock displays the time to press desired (6:00)
  • Page 20 to select comfort temperature. to press until the clock displays the time to press desired (10:30) Press to select the energy saving temperature THE. until the clock displays the time to press desired (18:00)
  • Page 21 THE. to select the comfort temperature to press until the clock displays the time to press desired (21:30) to select the night temperature. to press until the clock displays the time to press desired (0:00) The programming of 1-7 days (Monday to Domeni- ca) is ended.

  • Page 22: Copy Function

    to confirm and exit to press COPY FUNCTION 1. In automatic mode (icon on the display - see "functioning mode chin "on page 5), press and hold for more than 3 sec. the button . The written and the indicator will flash day. 2.
  • Page 23 The thermostat will sense N will work to Override temperature just set up the next event planned in the program (the icon indicating the functioning Manual override chin disappear from the display). To stop the Override press B • OVERRIDE FOR A CERTAIN NUMBER OF HOURS •...

  • Page 24: Alarm Function

    1 minute (after 15 seconds the display is no longer lit). The clock thermostat Sense N will work to Override temperature just imposta- ta until it exits the mode by pressing the button...

  • Page 25: Battery Replacement

    When the screen displays the symbol, you must be replaced as soon as possible the power of programmable thermostat batteries SENSE N. Changing the batteries in a matter of minutes, all the settings (program, temperature, date) They remain stored. You just need to reset the time.

  • Page 26: Maintenance

    MAINTENANCE The thermostat will, as a rule, does not require special maintenance. E 'suffi- you, if necessary, remove the dust with a soft, dry cloth or if necessary moistened with warm water and mild detergent. Caution: directions valid in EU countries where the product falls within the scope of application does the national law Caution: directions valid in EU countries where the product falls within the scope of application does the national law transposing the European Directive 2002/96 / EC, and therefore the obligation to separate collection at "end of life".

  • Page 27: Warranty Certificate

    WARRANTY This Guarantee is valid for industrial products and refers to products purchased for use. NOT include products purchased by companies, associations, professionals, in order to be used as part of their commercial or professional at-tivity. For industrial products the warranty period for the user is a year. •...
