Summary of Contents for Phantom Cables CA-NDB313-W
- Page 1 Wi-Fi Video Doorbell CA-NDB313-W Quick Start Guide...
-
Page 2: Quick Setup
Quick Setup Power Kit Installation Doorbell Installation Doorbell Setup... -
Page 3: What's In The Box
What's in the Box Mounting Plate (x3) Pick the one for best surveillance angle. Doorbell (x1) Faceplate (x3) Screwdriver (x1) Pick the one that best matched your home from Plate Foam (x1) three faceplates. Stabilize the mounting plate when installing it in the Drill Bit (x1) rough surface. - Page 4 • If you have mechanical chime installed in your home, install the power kit and doorbell. • If you have electronic chime installed in your home, refer to its own manual to install the power kit, and install the doorbell. Option B • If no chime is installed, skip power kit installation, install the doorbell and follow the in page 5.
-
Page 5: Wiring Overview
Connect the wire harness to the chime's terminals Insert the existing chime wire and the other end of the named TRANS and FRONT. wire harness into the wire connector and twist it tightly. Repeat this step with the other chime wire. Wire Connector Chime Wire... - Page 6 Doorbell Installation Recommended Installation Height: 4 feet (1.2 m) above the ground. Shut off the electricity at the breaker that controls (Optional) When the wall is uneven, paste the plate foam to the mounting plate. doorbell's circuit. Insert the mini-level into the mounting plate and mark Drill holes according to drill points and insert anchors.
- Page 7 Remove faceplate on your doorbell from buttom to top. Fix the mounting plate to the wall. Mounting Screw Option A; If not, follow Option If you have a chime installed, follow Option A Connect doorbell with your existing doorbell wires. Fixing Screw U-Shaped Wire Option B...
- Page 8 Fix the doorbell to the mounting plate by inserting the Restore the electricity at the breaker. doorbell screws. Doorbell Screw • Doorbell is powered on when its indicator flashes blue quickly. If not, make sure your electricity is off and check the wiring. If yes, proceed to doorbell setup. • For the first time use, please power on the doorbell and wait for 3 hours before using it, or else the chime in your home may not work.
-
Page 9: Led Indicator
Put the faceplate back and insert two security screws into the bottom of the doorbell to secure the faceplate. Security Screw Appendix Basics micro SD Card Terminals Mounting Holes Slot Reset Button Hold for 5s to reset and enter to AP mode. LED Indicator Blue Light Flashing... - Page 10 Use AP Mode for Wi-Fi Configuration -For AP hotspot configuration, press the Reset button for 5 seconds and then you will hear voice prompt. -Wait for a few seconds until you see the LED indicator flashes blue. -Follow the voice prompt to connect Wi-Fi. Wi-Fi Name: softap_XXXXXXXXX (9-digit Serial No.) Default Password: softap_XXXXXX (Verification Code) eg.
