Summary of Contents for Premium Supply RoaDCharger 20 Amp 7 Way
- Page 1 RoaDCharger 20 Amp 7 Way Installation Manual...
- Page 2 Safety First This symbol is used to call attention to instructions concerning personal safety. Be sure to observe and follow these instructions. Take time to be careful! WARNING indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury and includes hazards that are exposed when guards are removed.
- Page 3 Introduction: Congratulations on your new RoaDCharger! This device is going to help keep your trailer battery within its peak performance parameters, which will allow you greater productivity and lower cost of ownership. In this manual, we will cover the basic installation procedure, as well as some key tips for before and after your installation.
- Page 4 RoaDCharger Installation: Please follow the steps below and the diagrams / notes on the next few pages to ensure the RoaDCharger is installed properly. 1) First, remove the unit from the packaging and inspect for any damage during shipping (report immediately if there is damage). ...
- Page 5 7) Now take the male 7-way from the trailer and insert it into the 7-way female provided on the RoaDCharger. 8) Take the male 7-way that is provided with the RoaDCharger and route it through the tongue of the trailer to near the hitch. This will plug into vehicle 7-way.
- Page 6 Post Installation Checklist: This checklist ensures functionality of the electrical circuits on the trailer have not been affected during the installation. If any of these functions do not work, please stop work immediately and address the problem before moving forward with installation.
- Page 7 RoaDCharger Wiring Diagram: Connect To Vehicle 7 Way Connect To Trailer 7 Way...
- Page 8 Post Installation Notes: Wire Color Function Connect to Black Ground Vehicle ground Yellow Charger Output Charging Batteries Blue to battery lug Battery Temp Sensor Positive trailer battery terminal Local LED indicators: Power status/Standby Indicator (Blue LED): Solid ON while charging, OFF when the input voltage is too low either because of too much draw on the battery or the truck has been turned off.
