Smartcat Cat Climber Assembly Instructions

Assembly instructions for Cat Climber

Included components:

Bottom
Top

Step 1

Remove first nut from each bolt
Insert two bolts through the predrilled holes on each of the four shelves –
add the first nut back on the bolt but do not tighten (see figure #1 on back side)

Step 2

Start with the top piece, shelf one, and use the box to prop middle support (1 of 3)
Be sure to alternate direction of each shelf. Tighten bolt by hand and secure with wrench
Repeat until all four shelves are secured and bottom is attached (see figures #2-4 on back side)
At this time please go back and re-tighten all bolts and nuts.

Step 3

Lift climber and slide bottom bracket under the door, pull black top bracket and
stretch gently and secure top bracket onto door as shown.
For video instructions, please visit
Caution
Do not allow anyone to climb on this Cat Climber.
:
Not complying with the following warnings or modifying the product in any way
could result in damage, serious injury or death.
1. Do not climb on this product. This is not intended for Children.
2. Do not modify this product. It was designed to be installed in the manner
indicated in the installation instructions.
3. Do not substitute hardware. This product was designed to be installed
with the hardware provided.
4. Safety glasses must be worn to prevent eye injury when assembling
5. If you are unable to perform the installation as described, please contact
one of our customer service care representatives for installation
instructions 262 376 0768 or visit our web site
6. The door and frame must be structurally sound prior to installing product
7. Do not exceed the maximum weight limitations of 24lbs per shelf.
X3 Shelf
Middle X4
www.esmartcat.com
Bolt
X8
Bottom
