Summary of Contents for Arixet FSM103
- Page 1 STANDARD FSK MODEM F SM103 FSM203 User manual www.arixet.com ...
-
Page 2: Table Of Contents
DIAG PORT 7 REAR PANEL 8 Line / Analog interface 8 RS-232C / Serial data interface 9 Power supply 11 MOUNTING 11 Mounting FSM103 in rack 3U 11 FSM203 Desktop / Din rail mountable 13 ... -
Page 3: Introduction
3 FSM103, FSM203 USER MANUAL 1. INTRODUCTION FSM104 is a multistandard modem for asynchronous or transparent data transmission in 300-3400 Hz voice band. For lower baud rates it uses binary frequency ... -
Page 4: Interfaces
4 FSM103, FSM203 USER MANUAL 2. INTERFACES 2.1. FRONT PANEL Figure 2 FSM103 Front panel view (Rack mount version) ... -
Page 5: Power Key
5 FSM103, FSM203 USER MANUAL 2.1.1. POWER KEY Is accessible on the front panel and switched input power on and off . 2.1.2. LOOP K EY This key has 3 modes: Digital loop back In this mod data input from serial port loop back to itself. ... -
Page 6: Led Indicators
6 FSM103, FSM203 USER MANUAL 2.1.3. LED INDICATORS Figure 3 FSM103/FSM203 LED Indicators on front panel PWR PWR LED is ON when modem is power supplied; LOOP LOOP LED is ON when LOOP KEY is in digital or analog loop mode; ... -
Page 7: Configuration Dip Switches
7 FSM103, FSM203 USER MANUAL 2.1.4. CONFIGURATION DIP SWITCHES Figure 4 FSM103/FSM203 DIP Switches on front panel These configuration switches provide baud rate, inverse bit, output level and UART setting as following positions: Dip switch 1 ... - Page 8 8 FSM103, FSM203 USER MANUAL Dip switches 3,4,5 OUTPUT LEVEL OVER 600 Ω 3 4 5 PEAK RMS dBV OFF OFF OFF 0.50 V 0.35 Vrms -6 dBV OFF OFF ON 1.41 V 1 Vrms 3 dBV OFF ...
-
Page 9: Diag Port
9 FSM103, FSM203 USER MANUAL 2.1.5. DIAG PORT Figure 5 FSM103/FSM203 Diag port on front panel The RJ45 port for manufacture diagnostics and maintenance and its not applicable for user. 2.2. REAR PANEL ... -
Page 10: Line / Analog Interface
10 FSM103, FSM203 USER MANUAL 2.2.1. Line / Analog interface Figure 7 Pin configuration on line connector This connector is a SUB D 15 pin female type connector with screw locking, which provides: Interface between 4 wire analog line and the modem ... -
Page 11: Rs-232C / Serial Data Interface
11 FSM103, FSM203 USER MANUAL 2.2.2. RS-232C / Serial data interface The RS-232 serial data interface connector is a D-SUB 9 pin female type connector with screw locking. It provides the interface between the modem and remote terminal unit or data ... -
Page 12: Power Supply
12 FSM103, FSM203 USER MANUAL 2.2.3. Power supply Power supply connector is a 2-position screw plug type (for 2-2.5 mm 2 wire) used for ... -
Page 13: Mounting
13 FSM103, FSM203 USER MANUAL 3. MOUNTING 3.1. Mounting FSM103 in rack 3U Figure 8 Rack frame 3U/84TE/19” Front view Figure 9 Rack frame 3U/84TE/19” Rear view ... - Page 14 14 FSM103, FSM203 USER MANUAL Figure 10 Rack frame 3U/84TE/19” Side view Figure 11 FSM103 Card front view Figure 12 FSM103 Card rear view ...
-
Page 15: Fsm203 Desktop / Din Rail Mountable
15 FSM103, FSM203 USER MANUAL FSM203 Desktop / Din rail mountable 3.2. Figure 13 FSM203 Desktop front view and dimensions Figure 14 FSM203 Desktop rear view ... - Page 16 16 FSM103, FSM203 USER MANUAL Figure 15 FSM203 Desktop side view and dimensions Figure 16 Installing DIN RAIL mounting clamp on FSM203 Desktop (Right or Left side) ...
- Page 17 17 FSM103, FSM203 USER MANUAL Figure 17 Installing double DIN RAIL mounting clamps on FSM203 Desktop (Back side) ...
- Page 18 18 FSM103, FSM203 USER MANUAL ARIXET® STANDARD FSK MODEM USER MANUAL V1 JAN-2020 Manufactured By HOONAM TEL ...
