5.25" Open Bay
b
d
1U, 1U Redundant or Flex ATX Power Supply
1 21 0 JOHN R EED CT., CIT Y OF INDUSTRY, C A 91 74 5 | p : 626 - 81 0- 5 00 8 | f : 626-810-5555
WWW.AT HEN APOWER.COM
Front USB 2.0
ON/OFF Switch
HDD Indicator
Fan Controller Card
b
a
b
a
a
a
Up to ATX M/B
5.25" Open Bay
Power Indicator
b
a
Full High Expansion Slot
ATHENA POWER
your best computer mate
a.
stand offs for cable tie.
( Cable ties are included in the screw
package)
1.
Run the wires
through the cable tie.
2.
Secure the cable tie
onto stand off with
screw.
b.
Mounting bracket for 5.25"
bay
enclosure/
device.
(See figure 2.1)
c.
Mounting bracket for 3.5"
HDD. (See figure 2.2)
d.
Mounting bracket for 1U
power supply. (See figure
2.3)
*
All figures are located on the back of
this page
1U Rackmount Chassis / RM-DD1U12A
Advertisement
Table of Contents
Summary of Contents for Athena Power RM-DD1U12A
- Page 1 Full High Expansion Slot 1 21 0 JOHN R EED CT., CIT Y OF INDUSTRY, C A 91 74 5 | p : 626 - 81 0- 5 00 8 | f : 626-810-5555 1U Rackmount Chassis / RM-DD1U12A WWW.AT HEN APOWER.COM...
- Page 2 ATHENA POWER your best computer mate 5.25” Device & 3.5” HDD Installation 1. Remove the brackets from the RM-DD1U12A chassis 5.25” 2. Install the brackets onto the 5.25” device 3. Locate and secure the bracket back into the chassis with screws.
