Bosch 601295739 Parts List

60
801
5/1
4
33
8
19
801
19
2
28
13
3
27
Pos. Part Number
2 2 610 911 955
3 2 610 911 952
4 2 610 912 897
5/1 2 610 352 788
5/2 2 601 355 008
7 2 610 064 973
8 2 610 913 507
9 2 610 967 472
13 2 610 010 409
14 2 610 911 985
16 2 610 911 975
17 2 600 328 027
18 2 610 911 986
19 2 610 350 103
21 2 610 353 928
24 2 610 911 970
27 2 610 911 973
28 2 610 911 976
29 2 610 911 962
31 2 600 190 059
33 2 610 911 974
+ = Not Illustrated * = As Required
October 2001
INDUSTRIAL
60
806
7
40
21
5/2
810
34
16
801
62
62
9
35
14
4
40
X
Description {Qty}
Field 120V
Armature 120V
Switch On/Off
Terminal
Terminal
Cord Clamp
Nameplate
Label
Ball Bearing
Ball Bearing
Brush Holder
Drive Coupling
Ball Bearing
Rubber Pin {2}
Brush Spring {2}
Dampening Ring
Baffle
O-Ring
Skirt Assembly
Star Washer
Switch Cover
F/C = Failure Code
RANDOM ORBIT SANDER
Model 0601295739
805
29
18
17
815
31
24
c o r d
732
61
M
F/C Pos. Part Number
22 34 2 610 911 982
AW 35 2 610 991 485
15 40 1 607 233 145
10 50 2 610 069 666
10 60 2 610 323 769
89 61 2 603 414 050
9 62 2 610 315 386
9 650/2 1 907 950 006
60 650/3 2 610 914 127
61 732 2 608 000 124
25
40 732.1 2 608 000 123
51
66 732.2 2 608 000 125
27
79 801 2 610 914 073
24 805 3 604 460 555
78 806 2 600 703 018
73 810 2 610 353 931
65 815 2 610 911 980
9
AW = Refer to AW Labor Time Chart
1295DVS
650/3
50
X
29
62
650/2
Description {Qty}
Terminal {2}
Washer
Speed Control
O-Ring
Screw {5}
Screw
Screw {6}
Allen Wrench 5mm
Dust Cannister
Backing Pad - Medium
RS018
Backing Pad - Soft
RS019
BacKing Pad - Hard
RS020
Housing Assembly
Cord
Strain Relief
Brush & Spring Set (2ea.)
Dust Fan/Coupling Assy. 40
w/pos. 17, 18, 31
62
F/C
10
65
17
78
89
85
89
9
9
88
88
88
71
11
11
26
