IMPORTANT - Keep these instructions for future reference
Models Covered: 4141079, 4141299, 4141309
FOR CUSTOMER SERVICE
DO NOT CALL RETAILER OR RESELLER FOR SERVICE AS THEY ARE NOT
AUTHORIZED TO RESOLVE ANY SERVICE ISSUES.
FOR WARRANTY AND FEDERAL SAFETY STANDARD COMPLIANCE
ASSEMBLY INSTRUCTIONS
• Adult assembly required.
• Read all instructions BEFORE
assembly and use.
• Unpack carton, remove packing
materials, safely dispose of properly or
recycle where possible.
This stroller is for use of not more than 4 children
For use with children whose weight is 40 lbs, (18.14 kg) or less.
For use with children whose height is 45 inches, (114 cm) or less.
Children MUST be buckled in the seats with harness properly adjusted.
Foundations Worldwide, Inc.
Quad Sport Strollers
CERTIFICATES, PLEASE VISIT OUR WEBSITE AT
WARNING
Record product information here found
on the frame tube.
Manufacture Date:
Model Number: ________________
Purchase Order: ________________
1
.
.
Color and Style
May Vary
AB20049C
Advertisement
Table of Contents
Related Manuals for Foundations 4141079
Summary of Contents for Foundations 4141079
- Page 1 Foundations Worldwide, Inc. IMPORTANT - Keep these instructions for future reference Quad Sport Strollers Models Covered: 4141079, 4141299, 4141309 FOR CUSTOMER SERVICE DO NOT CALL RETAILER OR RESELLER FOR SERVICE AS THEY ARE NOT AUTHORIZED TO RESOLVE ANY SERVICE ISSUES.
-
Page 2: Table Of Contents
Table of Contents Table of Contents................Warnings................... Assembly instructions Tools and parts................Step 1- Rear Axle and Brake Assembly........Step 2 - Rear Wheel Assembly............. Step 3 - Front Wheel Assembly............ Step 4 - Arm bar Assembly............Step 5 - Canopy Assembly............Step 6 - Canopy Removal............Stroller operation and Use Unfolding and Folding Stroller............. Securing Children in Stroller............Seat Back Recline Adjustment............ Parking Brake Operation............. Front Wheel Swivel Lock Operation..........Arm bar Removal and Replacement..........Canopy Operation............... Stroller maintenance Cleaning.................. -
Page 3: Warnings
WARNING Failure to follow these warnings and assembly instructions could result in serious injury or death. Avoid Serious Injury To Children From Falling Or Sliding Out: • ALWAYS use harness to restrain each child. • Snugly adjust harness around each child. •... -
Page 4: Assembly Instructions
Assembly Instructions TOOLS REQUIRED: Phillips screwdriver • Read all instructions before ASSEMBLY and USE of Stroller. • Unpack carton, remove packing materials, including polybag. Identify and check all parts. If parts are missing or damaged, call Foundations for assistance ® • Discard all packing materials after assembly. WARNING • Choking Hazard - Stroller assembly hardware includes small parts. Keep small parts away from children. • Plastic bags can cause suffocation. Keep plastic bag away from children. -
Page 5: Step 1- Rear Axle And Brake Assembly
STEP 1 - Rear Axle and Brake Assembly Lay folded Stroller Frame Assembly (A) on Fig. 1 clean floor with handle tube (1) on top and front footrests (2) contacting floor (Fig. 1). Assemble Rear Axle Tube Assembly (C) to stroller (Fig. 2). - Position Rear Axle Tube Assembly (C) with brake tube (3) up and open end of rear axle assemblies toward rear legs. Style May Vary Fig. 2 - Slide rear axle tube assembly (C) onto the lower ends of rear legs (4) until contacting spring pins. Press spring pins and slide rear axle assembly (C) onto rear leg (4) until spring pins snap into holes in rear axle tube assembly (C) . - Pull on Rear Axle Tube Assembly (C) to check that it is secured onto rear legs. -
Page 6: Step 3 - Front Wheel Assembly
(Fig. 1) 2. Check the wheel is secure by pulling down on the wheels. Wheels should stay securely in place. AB20049_G4 STEP 4 - Arm Bar Assembly With Foundations logo on Arm Bar (E) facing up, ® Fig. 1 slide Arm Bar Clamp (1) between fabric seat side cover and front leg. Push Arm Bar Clamp (1) onto front leg tubes between the two Arm Bar Stops (2) and align the hole in the clamp with the Stud (3) on the arm, on both sides of the stroller (Fig. 1). -
Page 7: Step 5 - Canopy Assembly
STEP 5 - Canopy Assembly Fig. 1 To attach canopy: Main Position canopy with rounded front section on top Canopy and place canopy in rear seat area and over top Tube of front seats. Armrest Secure Main Canopy Tube (long tube) by pushing Canopy end of Main Canopy Tube into Canopy Retainer slot Retainer located on outside of handle near the armrest (Fig. 1). Handle Fig. 2 Secure short Rear Canopy Tube (short tube) by pushing end of Canopy Tube into Canopy Retainer slot located on outside of the handle near the top of the back seat (Fig. 2). Rear Repeat steps 2 and 3 to secure canopy tubes on other Canopy... -
Page 8: Step 6 - Canopy Removal
STEP 6 - Canopy Removal To remove canopy: Fig. 1 Open sides of canopy around stroller handle by pulling fabric hook & loop fasteners apart (1) (Fig. 1). Pull rear panel of canopy up and out of opening between stroller handle and handle support (2). Remove canopy from rear support tube by releasing hook & loop fasteners. Stroller Fig. 2 Handle Remove screw,retainer, and canopy strap from handle. (Fig. 2) Canopy Remove rear canopy tube (short tube) by Strap pressing retainer tab in (1) and sliding rear canopy tube up (2) (Fig. 3). Repeat step 5 for opposite side of stroller. Remove main canopy tube (long tube) by pressing retainer tab in (1) and sliding main canopy tube up (2) (Fig. 3). Fig. 3 Repeat step 7 for opposite side of stroller. Retainer Tab... -
Page 9: Stroller Operation And Use
Stroller Operation and Use Unfolding and Folding Stroller: WARNING • Pinch Hazard - Keep hands clear of moving parts during assembly, folding and unfolding. • Ensure that all the locking devices are engaged before use. Unfolding and Folding Stroller To unfold stroller: Fig. -
Page 10: Fig. 5
Unfolding and Folding Stroller To unfold stroller (continued): Visually check that the stroller handle is Fig. 5 securely locked into the fold Lock assembly on both sides of the stroller. (Fig. 5). NOTE: If fold lock is not locked, fold lock Fold can be locked by pressing down on Lock front of armrests and then press down on top of stroller handle. Stroller Stroller handle MUST Handle be locked into fold lock here, both sides To fold stroller: Place seat back of front seats in the upright adjustment position. NOTE: Seat backs of front seats must be in the upright position when folding. Fig. 1 Push down on Red Release lever on right side and then slide both Fold Lock Release collars on both sides up toward the handle grip to unlock (Fig. -
Page 11: Securing Children In Stroller
Securing Children In Stroller WARNING Avoid Serious Injury To Children From Falling Or Sliding Out: • ALWAYS use a harness to restrain each child. • Snugly adjust harness around each child. • NEVER leave children unattended, even when sleeping. Always keep children in view. •... -
Page 12: Seat Back Recline Adjustment
Seat Back Recline Adjustment Seat Back Recline Adjustment: The seat backs have two recline positions. Front seat adjustment: NOTE: The seat back must be in the upright position when folding the stroller. To recline seat back: Recline Fig. 1 Pull up on seat back Recline Handle (Fig. 1). Handle Lower seat back to recline position and release seat back recline handle. To raise seat back into upright position: Pull up on seat Back Recline Handle (Fig. -
Page 13: Parking Brake Operation
Parking Brake Operation. WARNING • Always lock parking brake when stroller is stopped and when loading and unloading children. To lock parking brake: Fig. 1 Press down on parking brake lock bar on the rear axle assembly into locked position (Fig. 1) Check that wheels are locked. Parking Brake Lock Bar To unlock parking brake: Fig. -
Page 14: Arm Bar Removal And Replacement
To Unlock Wheel Assembly: Fig. 1 Push swivel lock up to release (Fig. 1) Repeat for other wheel assembly. AB20049_G11 Arm Bar Removal and Replacement. To remove arm bar Fig. 1 Pull arm bar clamp lock lever out away from stroller to unlock arm bar from stroller frame (1). (Fig 1) 2. Pull out on arm bar to remove it from stroller frame (2) (Fig 1) To replace arm bar See step 4 in the assembly instructions, Arm Bar Assembly. • Only use Foundations provided or approved accessories for this stroller. -
Page 15: Canopy Operation
Canopy Operation Fig. 1 Front To extend canopy: Section Pull main canopy tube forward (1) (Fig. 1). Rotate front section of canopy forward (2) (Fig. 1). Main Canopy To retract canopy: Style May Vary Rotate front section of canopy back over Fig. 2 top of canopy (1) (Fig. 2). Pull main canopy tube toward rear of stroller (2) (Fig. 2). Front Section To operate canopy window: Main Canopy Tube Roll canopy window up towards top of canopy.
