Summary of Contents for Protero PV 212 Dump N Go
- Page 1 8722 E Research Center Rd. New Hope, MN 55128 Ph: 763-535-4038 DUMP N’ GO Fax: 763-535-4633 MODEL PV 212 JOHN DEERE Fits models: JOHN DEERE EZ-Trak ____________________________________________________________...
- Page 2 SAFETY Congratulations on purchase of your Protero PV 212 Dump N Go grass catcher! You will stay on your tractor seat and enjoy a beautiful lawn for a long time to come. Please read and be familiar with the operator’s manuals that came with your mower and grass catcher. These manuals provide information for the safest and most effective use of your equipment.
- Page 3 • Before you turn, slow down. • Avoid holes, rocks, and roots. • Mow up and down - not across slopes. • Do not park mower with material collection system on slopes. Parking Safely: • Stop machine on a level surface, not a slope. •...
-
Page 4: Tools Needed
INCLUDED PARTS AND HARDWARE: TOOLS NEEDED: • Phillips head screwdriver • Two, 7/16” wrenches (7/16” socket and ratchet suggested) • Two, 9/16” wrenches (9/16” sockets and ratchets suggested) • 15/16” wrench (15/16” sockets and ratchets suggested) • Pliers PARTS: ITEM # PART # DESCRIPTION QUANTITY... -
Page 5: Hardware Included
HARDWARE INCLUDED: ITEM # PART # DESCRIPTION QUANTITY BOLT HH 38 212 3/8” x 2 ½” HEX HEAD BOLT BOLT HH 38 2 3/8” x 2” HEX HEAD BOLT BOLT HH 38 1 3/8” x 1” HEX HEAD BOLT BOLT HH 14 114 1/4”... - Page 6 ASSEMBLY: STEP 1: • Pictured on left: Rear section of John Deere EZ-Trak Mower. • Pictured on right: JD EZ-Trak Rear Plate. (A) JD EZ-Trak Rear Plate JD EZ-Trak Spacer Plate 3/8” x 2” U-bolts (x4) 3/8" serrated flange nuts (x8) •...
- Page 7 STEP 2: Catcher Hinge Assembly 212 Hinge Bracket 3/8” x 2” hex head bolt (x4) 3/8” washer (x4) 3/8” nylock nut (x4) 3/8” x 1” hex head bolt (x2) 3/8” serrated flange nut (x2) Position the slotted holes of the •...
- Page 8 STEP 3: Dump Lever Assembly Dump Lever Handle 1/4" x 1 ¼” hex head bolt 1/4" nylock nut Insert the Dump Lever Handle into the Dump Lever Assembly • There are 3 holes for spacing the handle to clear the fender of the mower (correctly spacing the •...
- Page 9 STEP 4: 212 Channel Mount 1/4" x 2 ½” phillips truss head bolt (x4) 1/4" nylock nuts (x4) 3/8” x 1” hex head bolt (x4) 3/8” serrated flange nuts (x4) Position the Dump Lever Assembly to • the frame of the Catcher Body lining up the holes.
- Page 10 STEP 5: * Catcher Body removed from view. Lift up the current Catcher Body assembly and insert the Channel Mount into the JD EZ-Trak Rear • Plate (Channel Mount opening should face inwards toward mower).
- Page 11 STEP 6: 3/8” x 1” hex head bolt (x2) Hinges (on Door Assembly & Catcher hinge assembly) 3/8” nylock nut (x2) • Line up the hinges on Door Assembly with the hinges on the Catcher Hinge Assembly. • Keep the hinges on the Door Assembly to the right of the hinges on the Catcher Hinge Assembly.
- Page 12 STEP 7: Hood hinges go in between the Top Catcher Supports 3/8” x 7 ¼” bent pin Bridge pin 233 • Position the Hood Assembly on top of the Catcher Body. • Insert the 7 ¼” long bent pin thru the top holes of the Top Catcher Supports and thru the holes of the Hood hinges.
- Page 13 STEP 8: Hinge Rod – Right, Hinge Rod – Left (not shown in close up view) 3/8” washers (x4, 2 for each side of the Dump Lever Assembly) 1/8” Cotter Pin, 1” long (x2, 1 for each side of the Dump Lever Assembly) •...
- Page 14 STEP 9: 3/8” x 2 ½” hex head bolt (x2, 1 for each side of door assembly) 3/8” washers (x4, 1 for each side of door assembly) Rod End (x2, 1 for each side of door assembly) 3/8” nylock nut (x2, 1 for each side of door assembly) •...
-
Page 15: Limited Warranty
Our obligation under this warranty is expressly limited, at our option, to the replacement or repair at PROTERO Inc. (New Hope, MN), or at a service facility designated by us, of such part or parts as inspected shall disclose to have been defective. This warranty does not apply to defects caused by improper installation, damage, or unreasonable use (including failure to provide reasonable and necessary maintenance).
