SPECIFICATION SHEET
SPECIFICATION SHEET
29¾"
27 ⁄ "
29¾"
27 ⁄ "
8 ⁄ "
26⅞"
All measurements are approximate and may vary +/- 1/4"
www.maykke.com
Surrey 30" Fireclay Farmhouse Kitchen Sink
1"
Side
8⅞"
1¾"
18 ⁄ "
16"
9⅛"
14⅜"
17¼"
REV.08042017
10¼"
Advertisement
Table of Contents
Related Manuals for Maykke YSA1300101
Summary of Contents for Maykke YSA1300101
- Page 1 18 ⁄ ” 1” Front Side 29¾” 18 ⁄ ” 27 ⁄ ” 16” 9⅛” 8 ⁄ ” 9⅛” 8⅞” 26⅞” 10¼” 10¼” 14⅜” 5¼” 3⅝” 1¾” 1¾” 17¼” All measurements are approximate and may vary +/- 1/4" www.maykke.com SPECIFICATION SHEET REV.08042017...
- Page 2 Installation, Care Guide and Warranty Fireclay Apron Sink YSA1300101 YSA1310101...
- Page 3 Observe all state and local building codes. Carefully read all installation and care instruction before proceeding. PRE-INSTALLATION Tools Required MATERIALS INCLUDED (1) fireclay kitchen sink MATERIALS REQUIRED (2) 2x4 cut to fit in cabinet (1) 3/4” plywood www.maykke.com INSTALLATION AND CARE GUIDE REV. 05102017...
- Page 4 Cut 2 pieces of 2x4 beams to attach to the inside of the cabinet. Note: It is highly recommended to secure each 2x4 beam with wood glue and screws. See Figure 2. Figure 2. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05102017...
- Page 5 Cut the area for the faucet lines and drain / garbage disposal installation. Secure the plywood board with wood screws to the beams. Verify the board is level. See Figure 4. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05102017...
- Page 6 Place the sink over the plywood. Verify the overall appearance and check for levelness. See Figure 5. Step 6: Figure 6. Place the countertop over the cabinets and kitchen sink. Verify the countertop is level. See Figure 6. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05102017...
- Page 7 Step 4: Follow the directions on the silicone tube to allow for ample drying time. Refrain from moving/using the vanity during this time. Step 5: Install the faucet and drain per manufacturers instructions. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05102017...
- Page 8 • Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel. • Do not allow liquids and moisture to accumulate on the surface of products. • For warranty information, please visit our website at www.maykke.com or contact the Customer Service Department at (877) 659-2858.
