Summary of Contents for Zaxcom MicPlexer 2
- Page 1 USER MANUAL Published August 2014 interstage Phistersvej 31, 2900 Hellerup, Danmark Telefon 3946 0000, fax 3946 0040 www.interstage.dk - pro audio with a smile MicPlexer 2 Refined Distribution...
-
Page 2: Table Of Contents
KNOWING YOUR MICPLEXER 2 ........................3 ..................................3 RONT ..................................4 MICPLEXER2 OPERATIONS ..........................5 ..............................5 UPPLYING POWER ............................ 5 ONNECTING INPUT ANTENNAS ..........................5 ONNECTING OUTPUT ANTENNAS ............................ 5 ELECTING A FREQUENCY BLOCK ............................6 SING THE ARIABLE INPUTS Setting the variable filter ........................... -
Page 3: Knowing Your Micplexer2
Zaxcom MicPlexer2 Front Knowing your MicPlexer2 Front 1. SMA Antenna in Connection (2) SMA – Use only 50 Ohm connectors. 2. Overload LEDs 3. Power Switch 4. 16 Position Frequency Adjust Dial 5. Power LED 6. User Adjustable Filter Potentiometers... -
Page 4: Rear
Zaxcom MicPlexer2 Rear Rear 7. Antenna B outputs (4) SMA – Use only 50 Ohm connectors. 8. Antenna A outputs (4) SMA – Use only 50 Ohm connectors. 9. Power connector – Switchcraft 761K... -
Page 5: Micplexer2 Operations
Zaxcom MicPlexer2 Operations MicPlexer2 Operations Supplying power The MicPlexer2 uses a Switchcraft 761K locking connector and will accept 8 to 18 volts DC and has a power draw of 90mA at 12 volts. The center pin is wired positive and the ring is negative. -
Page 6: Using The Variable Inputs
Zaxcom MicPlexer2 Operations Using the Variable inputs The MicPlexer2 has two user adjustable settings V1 and V2. The variable positions allow you to custom set the center of the 35MHz filter to any frequency desired. This will allow the MicPlexer2 to be customized for any frequency range. -
Page 7: Product Support
Download the latest Firmware from: http://zaxcom.com/support/updates/ Download the latest User Manuals from: http://zaxcom.com/support/updates/ Submit Technical Questions at: http://www.zaxcom.com/submit-a-technical-question Submit information for Repair Services at: http://www.zaxcom.com/support/repairs Join the Zaxcom User Forum at: http://www.zaxcom.com/forum/forum.php Join the Zaxcom Face Book User Group at: https://www.facebook.com/groups/682199065139938/... -
Page 8: Specifications
Zaxcom Micplexer2 Specifications Specifications Frequency Tuning Range 512-702 MHz Tuned Pass Band 35MHz Attenuation: +/- 25 MHZ 12.5dB Attenuation: +/-50 MHz 35dB Attenuation: +/-75 MHz 51dB RF Gain 6 dB RF Channels Channel Crosstalk Less than 40 dB Amplifier Noise Figure .35dB... -
Page 9: Zaxcom Warranty Policy And Limitations
Distributers may sell Product to resellers who then sell Product to end users. Please see below for warranty information or obtaining service. No warranty service is provided unless the Product is returned to Zaxcom Inc. or a Zaxcom dealer in the region where the Product was first shipped by Zaxcom.
