- Page 1 C o n g r a t u l a t I o n s O N t h e p u r c h a s e o f y o u r ……. Arlo 2 Door TV cabinet ……. W e l c o m e t o a l o – 1 2 5 5‘...
- Page 2 Black. The Arlo TV Cabinet is constructed from NZ made MDF, a renewable resource from sustainably managed pine forests. This means you can have complete confidence that with The Arlo TV Cabinet, you are making an environmentally responsible choice.
-
Page 3: Parts List
ARLO – ALO-MP1255 PARTS LIST Please check you have all the necessary parts before beginning to assembling your TV Cabinet. The measurements provided will help you to identify each part. If any parts are missing or damaged please contact the manufacturers directly, either via our website or our 0800 number. Do not call the store you bought the cabinet from as they will be unable to help you. -
Page 4: Hardware List
ARLO – ALO-MP1255 HARDWARE LIST PART CODE Connecting Bolts 15mm Cams Dowels Large Screws Shelf Supports Pan Head Screws Pivot Hinge Magnetic Strike Plate Magnet Catch Pivot Hinge Sockets Black Nail-on Glides Bag of small Nails For assembly advice or parts go to www.farmersfurniture.co.nz or call 0800 100 858... -
Page 5: Install The Hardware
ARLO – ALO-MP1255 CAM INSTALLATION & OPERATION GUIDE The Cam and Connecting Bolt system is used to put your unit together. Below is an explanation of how this system works. To see a demonstration click on the assembly assistance tab at www.farmersfurniture .co.nz. - Page 6 ARLO – ALO-MP1255 Step 2 – Lh end Lay the LH End on a smooth clean surface with holes facing upwards. Insert two H2 15mm Cams as shown in diagram. Ensure the arrow on the top of the Cam points towards the top edge of the End.
- Page 7 ARLO – ALO-MP1255 Step 4 – centre division Lay the Centre Division on a smooth clean surface with holes facing upwards. Insert two H2 15mm Cams as shown in diagram. Ensure the arrow on the top of the Cam points towards the top edge of the Division.
- Page 8 ARLO – ALO-MP1255 Step 6 – base shelf Lay the Base Shelf on a smooth clean surface with holes facing upwards. NOTE: The Base Shelf has a purple mark on the back edge. Insert two H2 Large Cams into each end of the Base Shelf as shown in diagram. Ensure the arrow on the top of the Cam points towards the top edge of the Shelf.
-
Page 9: Assemble The Unit
ARLO – ALO-MP1255 ASSEMBLE THE UNIT Step 8 - Attach foot to base shelf Take the Base Shelf. Prop it on its back edge with the finished edge facing upwards. Take the Foot. Using two of the H5 Large Screws, fix the Foot to the unfinished side of the Base Shelf as shown below. - Page 10 ARLO – ALO-MP1255 Step 10 – Attach fixed shelf to centre division Take the Fixed Shelf. Fit the H1 Connecting Bolts installed in the Fixed Shelf to the H2 Cams installed in the top end of the Centre Division. Ensure that the finished edge of the Fixed Shelf is facing up.
- Page 11 ARLO – ALO-MP1255 Step 12 – attach LH End Take the LH End. Fit the H1 Connecting Bolts installed in the LH End to the H2 Cams installed in the Shelves. Tighten the Cams in a clockwise direction to lock the End to the Shelves. Ensure that the Cams turn at least a ¼...
- Page 12 ARLO – ALO-MP1255 Step 14 – attach divisions to top Take the Top. Lay it finished side down. Fit the H1 Connecting Bolts installed in the Top to the H2 Cams installed in the Divisions. Ensure that the finished edges of the Divisions are facing the same way as the finished edge of the Top.
-
Page 13: Step 16 - Back Panel
ARLO – ALO-MP1255 Step 16 – back panel Hold the Back Panel in Place as shown below, with the finished side towards the inside of the cabinet. The Back Panel will fit between the rebates in the back of the Base Shelf and the Fixed Shelf. -
Page 14: Glass Doors
ARLO – ALO-MP1255 Glass doors Step 19 – pivot hinge sockets Sit the Pivot Hinge Sockets in place in the predrilled holes in the Fixed Shelf and the Base Shelf as shown below. NOTE: if the Pivot Hinge Socket does not stay in place in the Fixed Shelf, you can leave it out for now... - Page 15 ARLO – ALO-MP1255 Step 21 – bottom pivot hinge Take one of the Pivot Hinges. Fit this to the long edge of the corner of the door opposite to the Magnetic Strike Plate. Tighten the screws in the Hinge until it holds the door firmly.
- Page 16 ARLO – ALO-MP1255 Step 23 – fit LH glass door While supporting the Door, ensure that the second Pivot Hinge socket is fitted in the pre-drilled hole in the left hand end of the Fixed Shelf. Fit the second Pivot Hinge to the hole in the top Pivot Hinge Socket. Ensure that the screws in the Pivot Hinge are facing inwards.
