GRASS SENSOMATIC Assembly And Operating Instructions Manual
Hide thumbs
Also See for SENSOMATIC:
- Assembly and operating instructions manual (132 pages) ,
- Start-up (100 pages) ,
- Assembly and operating instructions manual (147 pages)
Subscribe to Our Youtube Channel
Related Manuals for GRASS SENSOMATIC
Summary of Contents for GRASS SENSOMATIC
- Page 1 GRASS MOVEMENT-SYSTEMS SENSOMATIC OPENING SYSTEM Assembly and operating instructions www.grass.eu...
- Page 2 SENSOMATIC SENSOMATIC Assembly and operating instructions Translation of the original operating instructions...
-
Page 3: Table Of Contents
SENSOMATIC Table of contents Introduction ..........................23 Instructions for installers ..........................23 Signs and symbols in this instruction manual ....................23 Designated purpose ............................. 23 Safety instructions ........................24 General information ............................. 24 Safety instructions for assembly ......................... 24 General safety instructions ......................... 25 Repairs and modifications .......................... -
Page 4: Introduction
This means that they may only be connected and operated as described in the installation and ope- rating instructions. The Sensomatic must be mounted without connection to the power supply and installed in an enclosed cabinet. No modifications or additions of any kind to the approved mechanical and electrical functions are permitted, as these. -
Page 5: Safety Instructions
The Grass Sensomatic is a complete machine - see the Machinery Directive guidelines (edition 2.2.) The requi- rements of the Machinery Directive are fulfilled by the Grass Declaration of Conformity if the Sensomatic unit is installed in furniture in compliance with the current Grass specifications (catalogue, operating instructions, assem- bly instructions). -
Page 6: General Safety Instructions
Do not allow children to play within the movement range of drawers. „ Persons with a physical, sensory or mental impairment must not use this device. „ To secure GRASS Sensomatic systems against unintended opening, isolate the power „ supply unit. -
Page 7: Repairs And Modifications
SENSOMATIC Repairs and modifications Repairs and structural changes to the „GRASS Sensomatic“ opening system may only be carried out by an authorised specialist. The declaration of conformity issued by Grass is based on a risk assessment of stan- dard kitchen units. If furniture is not manufactured in accordance with the Grass catalogue, operating instruc- tions and assembly instruction specifications, conformity must be certified by the party placing the furniture on the market. -
Page 8: System Overview
SENSOMATIC System overview Drive unit Connection cable Opening lever Power supply unit Locking lever Power supply cable Frame cable Spring-loaded front buffers Translation of the original operating instructions... -
Page 9: Initial Start Up
SENSOMATIC 5.0 Initial start up Plug frame and connection cable into the power supply unit Connect adjacent cabinets with the connection cables Connect power supply unit to sock Synchronisation of drive units by means of a synchronisation cable Strip the synchronisation cable... -
Page 10: Disassembly
SENSOMATIC Disassembly Unplug the power supply unit Disconnect secondary cabinets from the connecting cable accordingly Disconnect the cross bar and connection cables from the power supply unit For disassembly of the drive unit see 8.1 Disassembly of synchronisation cable Disconnect the power supply unit from the socket... -
Page 11: Troubleshooting
SENSOMATIC Troubleshooting The drawers can always be opened manually like conventional drawers, even when isolated. It is often helpful to disconnect the system from the mains. Wait 10 seconds before switching the system on again. Fault Cause Remedy The drawer does The spring-loaded front buffer facilitating the Â... - Page 12 Power supply unit for up to 30 opening units Part number 112 ... Serial number SN ... Part number F121 ... F121131975 SENSOMATIC NOVA PRO/DYNAPRO GRASS GmbH Grass Platz 1 A-6973 Höchst SN 91329301000 24 V www.grass.eu CAUTION: FOR INDOOR USE ONLY ATTENTION: POUR UTILIZATION À...
-
Page 13: Maintenance And Care Instructions
SENSOMATIC Maintenance and care instructions Maintenance The GRASS Sensomatic drawer system does not require maintenance. Care instructions Live components! Electric shock! Defect of the opening unit „ Disconnect the drawer system from the mains before cleaning the drawers! „ Liquids or other substances in the power supply unit! Electric shock! Defect in the drive „... -
Page 14: Exchange/Disassembly Of The Drive Unit
SENSOMATIC Exchange/disassembly of the drive unit Dismounting the opening unit Live components! Electric shock! Disconnect the power supply unit from the mains before opening the locking lever! „ Translation of the original operating instructions... -
Page 15: Mounting The Opening Unit
SENSOMATIC Mounting the opening unit 1. left-hand side: attach 2. right-hand side: clip on) Translation of the original operating instructions... -
Page 16: Installation Dimensions
SENSOMATIC Installation dimensions Nova Pro installation dimensions Inside cabinet width (min. 262) Cable routing Ø 10 Ø 5/ 5 min. Inside cabinet width DWD XP installation dimensions Inside cabinet width (min. 262) Cable routing Ø 10 Ø 5/ 5 min. -
Page 17: Dynapro Installation Dimensions
SENSOMATIC Dynapro installation dimensions Inside cabinet width (min. 312) Cable routing Ø 5/ 5 min. Ø 10 Inside cabinet width 10.0 Adjusting the opening force High Medium Translation of the original operating instructions... -
Page 18: Technical Data
SENSOMATIC 11.0 Technical data 11.1 Power supply unit for up to 30 opening units Scope of application Movement Systems Nova Pro, Dynapro, DWD XP Range of application Only in dry indoor environments Power supply unit Power supply 100 to 240 V... - Page 19 SENSOMATIC Translation of the original operating instructions...
