BVECASE4
01/10/2019
Issue 1
ECR 3805
VIGIL Eclipse4
(BVECASE4)
Installation Details
Baldwin Boxall Communications Ltd.
Wealden Industrial Estate, Farningham Road
Crowborough, East Sussex, TN6 2JR
Telephone: 01892 664422
Fax: 01892 663146
Website: www.baldwinboxall.co.uk
Email: mail@baldwinboxall.co.uk
Advertisement
Summary of Contents for Baldwin Boxall VIGIL Eclipse4
- Page 1 BVECASE4 01/10/2019 Issue 1 ECR 3805 VIGIL Eclipse4 (BVECASE4) Installation Details Baldwin Boxall Communications Ltd. Wealden Industrial Estate, Farningham Road Crowborough, East Sussex, TN6 2JR Telephone: 01892 664422 Fax: 01892 663146 Website: www.baldwinboxall.co.uk Email: mail@baldwinboxall.co.uk...
-
Page 2: Precautions And Safety Information
4 (BVECASE4) CLIPSE The VIGIL Eclipse4 is a wall mountable, public address and / or voice evacuation system. The unit houses one BVRD2M4 (with termination PCB), one BVMBC battery charger, Network Interface modules (if required), suitable batteries and a choice of up to four amplifier mainframes. -
Page 3: General Safety Precautions
General Safety Precautions A U T I O N These Safety Precautions apply to assembled systems, however they may not all be applicable to every item within that system. Failure to follow these instructions and guidelines may cause personal injury and/or damage to the equipment. A R N I N G This equipment is intended for continuous operation and as such should be permanently connected to the mains supply. - Page 4 General Safety Precautions (cont.) A R N I N G Note that this equipment uses battery backup, and if the Mains Supply is disconnected Hazardous voltages will still be accessible on the terminals marked with the "High Voltage" symbol. A R N I N G The 24V DC batteries used within this system can deliver extremely high currents that can cause fire or burns.
- Page 5 BVECASE4 Mounting Holes and Knockout Positions Note: The BVECASE4 has been designed to allow cable entry from the top (via knockouts) or via the removable access plate in the rear panel. There is no requirement for ventilation or space either side of the installed position as all terminations can be accessed and maintenance operations can be performed from the front of the unit.
- Page 6 BVECASE4BATT Mounting Holes Note: The Adjustable feet should be set to ensure the BVECASE4BATT is flat and level to allow the BVECASE4 to be installed directly above it. - 6 - Issue 1...
