- Page 1 RS232, RS485. Connection and Operation of Galileosky Photo Camera User Manual www.galileosky.com...
-
Page 2: Table Of Contents
RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) Contents Necessary Tools, Devices, Materials ............3 General Information .................. 4 Connecting Photo Camera via RS232 Interface ........5 Connecting Galileosky Photo Camera via RS485 Interface...... 7 Setting the Parameters of Photo Camera Operating ........ -
Page 3: Necessary Tools, Devices, Materials
RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) Necessary Tools, Devices, Materials To Connect Galileosky photo camera to the Galileosky tracking device (hereinafter - tracking device) one should have: Electrical tools. Set of connecting wires. -
Page 4: General Information
The camera is designed for shooting and the subsequent transfer of pictures to the monitoring server from the vehicle and (or) from stationary installation sites. The camera is to be installed together with Galileosky and Galileosky GPS/GLONASS tracking devices and can be used for: 1. -
Page 5: Connecting Photo Camera Via Rs232 Interface
(version 3 dated from August 8, 2018) Connecting Photo Camera via RS232 Interface The camera is connected to the Galileosky v. 5.0 tracking unit via RS232 according to the scheme presented in Picture 2. Pic. 2 Connection scheme of the camera to Galileosky v. - Page 6 RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) - go to tab Device in the Configurator and reset the tracking unit by clicking button “Reset device” or in the Command tab send command “reset”.
-
Page 7: Connecting Galileosky Photo Camera Via Rs485 Interface
(version 3 dated from August 8, 2018) Connecting Galileosky Photo Camera via RS485 Interface The camera is connected to the Galileosky v. 5.0 tracking unit via RS485 according to the scheme presented in Picture 5. Pic. 5 Connection scheme of the camera to Galileosky v. - Page 8 RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) - go to tab Commands of Configurator and send command “makephoto”; - go to tab Troubleshooting and tick the option “RS485”. The example of troubleshooting message for firmware up to 229 is presented below: RS485.cam.
-
Page 9: Setting The Parameters Of Photo Camera Operating
RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) Setting the Parameters of Photo Camera Operating You can set additional parameters of operation with the camera in the tab settings -> Digital inputs (Pic. 7), or by the command PhotoCfg (see the description in the Appendix 1). - Page 10 RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) Parameter “Recording in geofence” defines the behavior of the tracking unit on taking pictures by the camera depending on the use of Geofences. Parameter “Size” allows you to set the picture resolution: 640х480 or 320х240 points.
-
Page 11: Uploading Photos From Microsd Card
For that send command with necessary parameters (see the description in Appendix 1). Connection of Galileosky photo camera and Galileosky tracking unit is completed, the tracking device is ready for use. RSA “Galileosky”, LLC produces satellite monitoring equipment for GPS and GLONASS real time vehicles monitoring. - Page 12 RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) APPENDIX 1 Photo camera operation settings Command format GetPhoto d,t,n Parameters d – photo date, format DDMMYY, where DD – day, MM – month, YY – year;...
- Page 13 RS232, RS485. Connection and Operation of Galileosky Photo Camera (version 3 dated from August 8, 2018) Command format MakePhoto Explanation Take a photo and send it to the server Example Request: MakePhoto Reply: Photo ok...
