HydroCleaner
Model #: HC-02
OPERATOR'S MANUAL
WARNING:
Improper use and/or failure to follow instructions may result in serious injury. Carefully read all instructions
before use. Never spray flammable, caustic, acidic, chlorine, bleach, petroleum, non-water based, or
other corrosive solutions or heat, pressure, or gas producing chemicals. ALWAYS follow chemical
manufacturer's SDS instructions.
DOC: PASU052720-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HydroCleaner HC-02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Premier HydroCleaner HC-02

  • Page 1 HydroCleaner Model #: HC-02 OPERATOR’S MANUAL WARNING: Improper use and/or failure to follow instructions may result in serious injury. Carefully read all instructions before use. Never spray flammable, caustic, acidic, chlorine, bleach, petroleum, non-water based, or other corrosive solutions or heat, pressure, or gas producing chemicals. ALWAYS follow chemical manufacturer’s SDS instructions.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS A. TABLE OF FIGURES 1. MAIN COMPONENTS 1.1 HYDROCLEANER FIGURES 1.2 MAIN COMPONENTS LIST 2. PRODUCT SPECIFICATIONS 3. SAFETY INFORMATION 4. OPERATION 4.1 BEFORE USE CHECKLIST 4.2 FILLING THE TANK 4.3 OPERATING PROCEDURE 4.4 SPRAY ADJUSTMENT 5. CARE INSTRUCTIONS 5.1 EMPTYING THE TANK 5.2 RINSING THE SYSTEM 5.3 HANDLE HEIGHT ADJUSTMENT...

  • Page 3: Table Of Figures

    A. TABLE OF FIGURES FIGURE 1.1.1 Overall View (w/Skin) FIGURE 1.1.2 Front View (w/o Skin) FIGURE 1.1.3 Rear View (w/Skin) FIGURE 1.1.4 Side View 1 (w/o Skin) FIGURE 1.1.5 Pump Tank Bottom View FIGURE 1.1.6 Top View w/ Top Access Panel Open FIGURE 1.1.7 Side View 2 (w/o Skin) FIGURE 1.1.8 Handle Base FIGURE 1.1.9 Spray Gun...

  • Page 4: Main Components

    1. MAIN COMPONENTS 1.1 HydroCleaner Figures: FIGURE 1.1.1 Overall View (w/Skin) FIGURE 1.1.2 Front View (w/o Skin) FIGURE 1.1.3 Rear View (w/Skin) FIGURE 1.1.5 Pump Tank FIGURE 1.1.4 Side View 1 (w/o Skin) Bottom View FIGURE 1.1.6 Top View w/ Top Access Panel Open FIGURE 1.1.7 Side View 2 (w/o Skin) FIGURE 1.1.8 Handle Base FIGURE 1.1.9 Spray Gun...

  • Page 5: Main Components List

    1.2 Main Components List: COMPONENT COMPONENT COMPONENT HANDLE AIR HOSE INLET HANDLE LOCKING PIN SPRAYER HOSING PUMP PRESSURE GAUGE PIN CLAMP HANDLE HEIGHT ADJUST HIGH TOP ACESS PANEL LIQUID HOSE INLET (VERTICAL POSITION) TANK DRAIN VALVE (FOR UNIT HANDLE HEIGHT ADJUST MEDIUM (45° TOP ACESS PANEL HANDLE W/SKIN) POSITION)

  • Page 6: Safety Information

    3. SAFETY INFORMATION WARNING  Read and understand all instructions before  Do not use in hazardous environments or in the handling and operating unit. presence of flammable liquids, gases, or dust. Beware of all hazards in area and in combination ...

  • Page 7: Operation

    4. OPERATION 4.1 Before Use Checklist: 1. Make sure to wear all necessary PPE (per the environment and SDS of any chemical solutions) when handling the HydroCleaner. 2. If system was not depressurized after last use, the spray gun may be pressurized. 3.

  • Page 8: Filling The Tank

    FIGURE 4.1.2 Bottom View of Pump Drain Plug Pump Drain Plug Rotate valve counterclockwise to open/drain. iv. Carefully remove the drain pan and safely dispose of the collected water. v. Close the drain valve by turning the handle 90° clockwise to be parallel with the pump tank.

  • Page 9: Operating Procedure

    5. Unscrew the two clamps on the lid of the tank. 6. Lift and remove the lid. 7. Carefully pour the solution into the tank. Do NOT exceed the capacity of the tank (max 2.5gal of liquid). Use a funnel as needed for pouring. 8.
  • Page 10 FIGURE 4.4.1 Spray Gun Liquid and Direction Adjust Spray Gun Liquid Adjust Clockwise = Restrict Flow Counterclockwise = Increase Flow Spray Gun Air Cap/Direction Adjust Rotate protruding part to change direction. Do NOT exceed 360° and loosen cap. 5. The air flow of the sprayer may be adjusted by rotating the knob clockwise to increase air flow and counterclockwise to decrease air flow (see Figure 4.4.2).

  • Page 11: Care Instructions

    9. Typically, the spray regulated pressure is set between 35-45 PSI, but pressures may vary. a. To change the spray regulated pressure, rotate the spray pressure regulator (see figure below) clockwise to increase pressure and counterclockwise to decrease pressure to set at desired pressure setpoint.

  • Page 12: Rinsing The System

    5.2 Rinsing the System: 1. Once the tank is empty, it will need to be rinsed thoroughly with WATER. 2. Unscrew the two clamps on the lid of the tank. 3. Rinse the interior of the tank lid and hosing and clean/rinse thoroughly (in accordance with SDS instructions).

  • Page 13: Storage

    5.4 Storage: 1. Make sure power is off and the unit is unplugged. 2. Follow Care Instructions to rinse and empty the tank before storing. 3. Drain the water from the pump unit (see Before Use Checklist 4.1.6.b) and depressurize the system. 4.

  • Page 14: Warranty

    Premier Engineered Cleaning Solutions, LLC warrants each new Premier product to be free from defects in material and workmanship. This warranty is applicable only for the normal service life expectancy of the machine or components to not exceed twelve consecutive months from the date of delivery of the new Premier product to the original purchaser.
