L&L NEVA 5.0 Installation Instructions Manual page 4

NEVA 5.0 - 5.1 - 5.2
Installation instructions -
LED
24 IP67
Vdc
TECH
3
4
24Vdc + PWM (Neva 5.0 - 5.1 - 5.2)
24Vdc + DMX 512 + RDM (Neva 5.0 DMX)
L&L Luce&Light srl
Via Della Tecnica, 42 - 36031 Povolaro di Dueville (VI) - Italy
Tel. +39 0444 360571 - Fax +39 0444 594304
Istruzioni per l'installazione
PWM IK06
CONNESSIONE STAGNA!
Waterproof connections!
www.lucelight.it - lucelight@lucelight.it
RoHS
T 40°
compliance
Ta 25°
CONNETTERE RISPETTANDO LA POLARITA'
LED LIGHTS MUST BE CONNECTED
RESPECTING POLARITIES
NERO
BLACK
ROSSO
RED
VERDE
GREEN
BLU
BLUE
Made in Italy
Pag. 4 - rev.06
