Page 2
LANCNC ftp data server. Requirements The LANCNC device will work with a CNC control with a standard DB25 RS-232 serial connection to the control box for the purposes of input/output of CNC data. Typically, the CNC manufacturer refers this as read and punch tape functions.
Page 3
The LANCNC kit includes a mounting bezel that also acts as a drill jig. Once the installer has identified where the display should be mounted, the mark the small hole in the center and drill a hole the same size. Mount the plate, level and tighten to the cabinet. Please note to use best method to manage the metal chips created when drilling the holes.
Page 4
Mount the display and bracket to the control box. Inside the cabinet the RJ11 and the potentiometer should be visible through the large diameter hole.
Page 5
Secure the din rail as shown below. Attach the din rail clips to the LANCNC controller and mount to the din rail. Check for spacing. The two outer holes from the din rail clips can be used to release from the clips with a small screwdriver.
Page 6
Note, Calmotion uses standard CAT5 patch cable as a RS-232 cable. Do not confuse this with the LAN CAT5 that is used with the Ethernet network that will connect to the LANCNC at J7. Plug the RS-232 RJ45/DB25 plug into the X1 DB25F on the control board. The control board uses a straight cable connection.
Page 7
connectors have been provided. Choose one as appropriate. In most cases, it is best to simply pull the serial connector in from its mounting assembly and connect inside the pendant as shown below. Figure 1 Connect the power plug provided to the printed circuit board. The power connection is center positive.
Page 8
Figure 2 Please refer to the LANCNC user’s manual for operation and communication set-up of the LANCNC.
