Summary of Contents for MSA Luminator Cap Lamp
- Page 1 Operating Manual Luminator Cap Lamp Order No.: 10153186/00 MSAsafety.com...
- Page 2 MSA AUER GmbH D-12059 Berlin Thiemannstraße 1 Germany © MSA AUER GmbH. All rights reserved...
- Page 3 The product is in conformance with the directive 2004/108/EC, (EMC): EN 61000-6-2:2006, EN 61000-6-4:2007 The product is in conformance with the directive 2006/66/EC. MSA AUER GmbH Dr. Axel Schubert Manager R&D Instruments & Approvals INT-T Berlin, July 2013 Luminator Cap Lamp...
-
Page 4: Table Of Contents
Cleaning ................... 13 Technical Data ................... 14 Approvals ....................15 Marking, Certificates and Approvals according to the Directive 94/9/EC (ATEX) ............15 Marking and Certificates according to IECEx ........16 Marking and Certificates according to SANS ........17 Ordering Information ................17 Luminator Cap Lamp... -
Page 5: Safety Regulations
Alternative use, or use outside this specification will be considered as non-com- pliance. This also applies especially to unauthorised alterations to the product and to commissioning work that has not been carried out by MSA or authorised persons. Liability Information MSA accepts no liability in cases where the product has been used inappropri- ately or not as intended. -
Page 6: Safety And Precautionary Measures To Be Adopted
Do not charge in hazardous areas. Recycling of Batteries Used batteries must be returned to the dealer or manufacturer for disposal. They should never be disposed of in household waste. Luminator Cap Lamp... -
Page 7: Description
Description Description Overview Fig. 1 Overview Luminator Cap Lamp Battery Pack Headpiece with RFID Tag Cable Gland Bezel Ring Cable Lock Screw / Charger Contact [Positive] ON/OFF Button Clip / Protected Charger Contact [Minus] Luminator Cap Lamp... -
Page 8: Labels
Description Labels The battery pack is equipped with 3 labels: User defined Label Luminator Cap Lamp... -
Page 9: Cable Management
The cable length can be adjusted by fixing the cable at the end of each belt loop (cable fixing). Total lenght of the cable: 160 cm Fixing at 1 side (2 cable fixings): 10-15 cm shorter cable Fixing at 2 sides (4 cable fixings): 30-60 cm shorter cable Luminator Cap Lamp... -
Page 10: Donning
(3) Lay the cable at the back, to move freely. (4) Attach the headpiece with the clip on the helmet. (5) Insert the cable into the clamp at the back side of the helmet. Luminator Cap Lamp... -
Page 11: Use
(2) Press the ON/OFF button to turn off the device. Changing Operation Mode The device is equipped with at least 3 operation modes. Mode 1: Extended walking light Mode 2: Working light and extended walking light Mode 3: Working light Luminator Cap Lamp... -
Page 12: Battery Warning
(3) Turn the headpiece 180 degree to start the charging process. The charge time is up to 12 h for a complete depleted battery pack and less than 6 h after an 12 h working shift. Luminator Cap Lamp... -
Page 13: Maintenance
(2) Gently press the ON/OFF button, to check the operation mode. Cleaning Do not use solvents to clean the device. (1) Clean the device with a clean soft cloth. (2) Avoid any cleaning method that may lead to scratching of the lens or re- flectors. Luminator Cap Lamp... -
Page 14: Technical Data
> 4.0 cd Correlated Color 4,000 K Temparature [CCT] Color Rendering Index > 93% [CRI] Ingress Protection IP 68 Cable length 1.60 m Run time Up to 36 h Emergency light after 100 h 8 h shift Luminator Cap Lamp... -
Page 15: Approvals
Special conditions for safe use: The antenna used for the activation of the transponders in an hazardous area must only be with the RF radiation power not exceeded 6 W for Group I and 2 W for Group IIC. Luminator Cap Lamp... -
Page 16: Marking And Certificates According To Iecex
The charging of the LUMINATOR is only allowed outside of the hazardous area. For charging follow the manual instructions (5 V/1 A, U = 7 V). Quality Assurance Notification: 0158 Year of Manufacture: see Label Serial Nr.: see Label Luminator Cap Lamp... -
Page 17: Marking And Certificates According To Sans
Year of Manufacture: see Label Serial Nr.: see Label Ordering Information Description Part No. Luminator, Cap Lamp, Heavy Duty 10150602 Luminator, Cap Lamp, Heavy Duty (20 pieces) 10153597 Charger Stand, Luminator 10153261 Charger power supply, Luminator 10153262 Luminator Cap Lamp... - Page 18 No. 8 Rui En Lane, Xingpu Road 51 Ayer Rajah Crescent 30-16, Nishiwaseda 3-chome CEP 09990-901 Diadema Suzhou Industrial Park Singapore 139948 Shinjuku-ku Sao Paulo- Brazil (Brasil) Jiangsu For further local MSA contacts please go to our web site www.MSAsafety.com. MSAsafety.com...
