ProTube™ BUMPER/GRILLE GUARD

PARTS LIST

7
Item
Part
Qty Description
1
26242
1
Label, ProTube
2
28524
1
ProTube Bracket, DS
4
*
2
1/2-13 x 4 Hex Cap Screw G5
5
*
10
1/2 Flat Washer
6
*
2
1/2-13 Hex Locknut GB
7
*
4
3/8-16 x 1-1/4 Hex Cap Screw G5
ns = not shown
WARNING
Do not exceed GVWR or GAWR, including
blade and ballast. The rating label is found on
the driver-side vehicle door cornerpost.
CAUTION
Read this document before installing the
ProTube bumper/grille guard.
Fisher Engineering
50 Gordon Drive, Rockland, Maine 04841-2139 • www.fi sherplows.com
8
3
8
1
ProTube Bumper/Grille Kit
28526 Bolt Bag
* = available as part of bolt bag only
A SUBSIDIARY OF DOUGLAS DYNAMICS, L.L.C.
9
6
5
Item
Part
Qty Description
3
28523
1
ProTube Bracket, PS
ns
28526
1
Bolt Bag
8
*
8
3/8 Flat Washer
9
*
4
3/8-16 Hex Locknut GB
10
*
2
Clamp
Use standard methods and practices
when attaching snowplow and installing
accessories including proper personal
protective safety equipment.
See your FISHER
®
vehicle application recommendations before
installation. ProTube guard weight information
may be found in the Kit Selection Guide.
26239 – Stainless
26240 – Black
March 15, 2010
Lit. No. 26244, Rev. 06
