Summary of Contents for RC-Upgrade Globe Flight Black Snapper CFK
- Page 1 Black Snapper Black Snapper CFK – Folding quadrocopter by RC-Upgrade Preliminary assembly manual Status: October, 2013 page | www.globe-flight.de...
- Page 2 Step 1: Installation of the motors on the motor mounts Please slightly loosen the screws with which the motor mount is attached to the boom, then pull the whole mount off the boom. Thread the motor cables through the provided protection grommet at the end of the motor mount and screw the motor on the mount.
- Page 3 Step 5: Installation of the ESCs and the cable harness As you can see in the picture, the ESCs are positioned on the outside of the bridge walls. This position is very important for the folding mechanism to work accurately. If you don’t use a power distribution board, you need to solder a cable harness.
- Page 4 Step 7: Mounting of the booms. Important: The order and orientation of the washers has to be kept as it was delivered. On the outside of the frame there is a flat washer, between the frame and the POM plastic there is a curved washer.
- Page 5 Hints for users of the Black Snapper Brushless Gimbal with AlexMos controller If you want use your Black Snapper with the Black Snapper Brushless Gimbal GoPro 3, you need an additional controller, for example the Brushless Gimbal Controller by AlexMos. You can find the respective sources online, e.g.
- Page 6 The gimbal itself must be set to maintain that the motors have to “work” as little as possible. Thereby, you should keep the following in mind: The center of gravity of the gimbal can be shifted by moving the motor for the roll function, additionally you can change the wiring e.g.
- Page 7 Of course, these settings must still be adjusted to your own gimbal, but it should already work quite well with these settings. The values refer to the “SimpleBGC GUI v2.2” Important: The mounting orientation of the sensor on the gimbal must be trained! This has to be done in the section “Basic-Sensor”.
- Page 8 Hint for users of the landing skids: The landing skids must be pointing OUTWARDS to ensure that the copter stands steadily even in folded up state. page | www.globe-flight.de...
