This guideline describes the recommended installation procedure and maintenance for the STT SCRmarine system
STT Emtec AB (pbl)
Box 46, Njurundavägen 16A
SE-862 02 NJURUNDA
SWEDEN
Document
STT SCRmarine
Installation Guideline
Installation Guideline
Latest version available at www.sttemtec.com
Tel: +46 (0)60-64 10 40
Fax: +46 (0)60 64 10 45
e-mail: info@sttemtec.com
Internet: www.sttemtec.com
Date
Page 1
2019-05-15
Issue: 1.8
Head office: Njurunda
Org.nr: 55 62 05 – 2927
VAT ID: SE556205292701
ISO-cetrifikat nr: 15627

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCRmarine and is the answer not in the manual?

Questions and answers

Related Manuals for STT Emtec SCRmarine

Summary of Contents for STT Emtec SCRmarine

  • Page 1 STT SCRmarine 2019-05-15 Issue: 1.8 Installation Guideline Installation Guideline This guideline describes the recommended installation procedure and maintenance for the STT SCRmarine system Latest version available at www.sttemtec.com STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A...

  • Page 2: Table Of Contents

    3.7.1. Function 3.7.2. Installation 3.7.3. Maintenance 3.7.4. Replacing the DEF filter 3.7.5. Replacing the DEF dosing unit STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 3 5.4.6. Diagnostic trouble codes 5.4.7. “Normal” trouble codes 5.5. External diagnose options 5.5.1. Slave display panel 5.5.2. PC diagnose software STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
  • Page 4 Installing discrete engine sensors Appendix 13 PC diagnose manual (EmtecDiag) Appendix 14 Retrieving diagnose data STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...

  • Page 5: Purpose

    1 Purpose The purpose of this document is to give sufficient information on how to install and operate the key components of the SCRmarine system. The installation guideline also describes the post adjustments and inspection processes and gives general information on service and maintenance.

  • Page 6: System Overview

    2019-05-15 Issue: 1.8 Installation Guideline 1.2 System overview The schematic diagram in Figure 1 shows the layout of the SCRmarine system. It is a fully automated after-treatment NOx reduction system with simple calibration and low maintenance requirements. Figure 1. SCR marine system, arrangement and layout 1.

  • Page 7: Components Overview

    2019-05-15 Issue: 1.8 Installation Guideline 1.3 Components overview The following are the key components of the SCRmarine system. Some parts are optional, such as the POC (Particle Oxidation Catalyst). Appearance and contents can vary between specific systems. DEF Service Tank...

  • Page 8: System Requirements

    Installation Guideline 1.4 System requirements The SCRmarine is an automatic NOx reduction system. It is based upon a NOx sensor measuring the actual emissions from the engine and therefore requires little or no calibration during commissioning. An SCR catalyst assembly, and optionally a POC (Particulate Oxidation Catalyst), is installed in the exhaust line as close to the engine as possible to preserve exhaust temperature.

  • Page 9: Exhaust Components Installation

    The canning of the exhaust components is produced of stainless steel with flanges on the in- and outlet ports. The shape of the flanges can differ due to regulations and/or customer demands. Please observe the type of flanges in the BOM for your SCRmarine installation kit.

  • Page 10: Thermal Expansion

    It is important to leave space for the insulation at the installation. In a typical installation the insulation is minimum 50 mm thick. Additional insulation may be required according to regulations and/or customer demands. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A...

  • Page 11: Exhaust Mixer And Scr Chamber (Scr Assembly)

    NOx converting function of the catalyst. NOx conversion verification must be performed by trained personnel only; please contact STT Emtec for more information. See also Appendix 03 – Maintenance for further information...

  • Page 12: Poc (Particle Oxidation Catalyst)

    Insulation. Additional brackets to support the POC assembly may be needed depending on the surroundings and support of other parts. STT Emtec recommends the use of metal resilient elements type Vibratec® or similar. Additional insulation may be used according to regulations and/or customer demands.

  • Page 13: Def Dosing Components Installation

    Installation Guideline 3 DEF dosing components installation This section provides information on installing and maintaining the DEF dosing components of the SCRmarine. 3.1 General The dosing components are designed to carry liquid DEF from the service tank to the exhaust stream. When dehydrated the DEF solution will form salt deposits from its Urea content.

  • Page 14: Def Supply Lines

    107995 107999 107996 108344 108345 Figure 9. PA hose, 0.4m STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...

  • Page 15: Def Service Tank

    An automated service tank refill system should implement a high level alarm. The recommended material selection for a bulk tank is chromium nickel or chromium nickel molybdenum steel. Note that no forms of copper alloy are allowed. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A...

  • Page 16: Tank Heating

    Any air equipment that has been polluted with DEF has to be replaced. DEF liquid or crystals in the air inlet can cause blockage and damage to the DEF dosing unit! STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A...

  • Page 17: Unit

    Note! Do not attempt to disable the DDS by shutting off the air supply! Blockage or damage to the injection components may occur! See section Operating procedures – System shutdown. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A...
  • Page 18 Gauge/manometer 108859 Pressure switch 108984 Figure 14. FR unit Spare parts STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 19 If the compressed air supply includes an air dryer, then if possible, take the air supply to the urea pump before the air dryer. If a compressed air system is not available a separate air compressor has to be installed. Table 7 below contains STT Emtec’s recommendations for the air compressor.
  • Page 20 Detail Part no below default position is not ok! DEF supply pump 108918 STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 21 3.7.2 Installation The DDU is available in different dosing ranges, see table 9. Please observe the type of DDU in BOM of your SCRmarine installation kit. For proper function, the DEF dosing unit should be oriented, as shown in figure 20 above.
  • Page 22 DEF dosing unit, 13 kg/h 108830 DEF dosing unit, 31 kg/h 108961 Exhaust backpressure sensor 103407 STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 23 Note! Do not use copper or brass in compression fittings! Note! Avoid air pockets when routing DEF lines or blockage may occur! STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
  • Page 24 DEF pressure regulator 108828 Air solenoid valves, assy 103629 Air check valve 102601 STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 25 Note! When releasing the DEF- and the electric connections, make sure no DEF gets in contact with the connector receptacles! STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A...
  • Page 26 Note! The inside radius of the hose must not be bent narrower than 125mm. Note! In case of a vertical stack, there must be a water trap installed between the injection point and the engine. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
  • Page 27 107457 Injection nozzle, 8” / 1500mm 108666 Injection nozzle, 5.5” / 1500mm Figure 31. Injection nozzle STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 28 Bracket 4.1.3 Maintenance Check tightening of the terminal screws every 24 mon or 6000h, see Appendix 03 - Maintenance STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
  • Page 29 Emergency stop switch Start switch (Em.Stop reset) LCD display unit 107258 STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 30 Figure 36 shows the allowed NOx sensor mounting positions. Figure 36. Orientation of the NOx sensor control unit STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
  • Page 31 105379 Plug for mounting boss 108855 Cu washer for mounting boss 105637 STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 32 Temperature sensor SCR inlet, 1m 108925 Figure 42. Temperature sensor SCR outlet, 1m 108924 Temperature sensor STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 33 Note! Ensure that the exhaust back pressure hoses are routed uphill from the exhaust pipe to the pressure sensor to enable drainage of condensed water. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
  • Page 34 Part no EBP extension cable, 10m 108365 Figure 47. Pressure sensor, vertical stack STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 35  Engine running signal See section Cables for detailed information Note! Use only cables delivered, or specified, by STT Emtec AB to ensure proper system operation! The electrical installation kit includes a full set of installation cables. All cables are connected from the side terminal rail of the SCRmarine control cabinet (Figure 49) to each respective DDS system component.
  • Page 36 (sensor, actuator, power supply etc). The position numbers in the figure corresponds to the cable No in the wire installation chart. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A...
  • Page 37 1. TANK, 2. NOX, 3. CAN, 4. PUMP, 5, 6. EBP, EBPb, 7. NOX2, 8. MAP, 9. OBD, 10. COM, 11. RUN, 12. AIR, 13. ALA, 14. RPM, 15. MIT, 16. DDU, 17, 19. Tscr1, Tscr1b, 18, 20. Tscr2, Tscr2b, 21. SUPPLY Note that not all cables may apply to your specific SCRmarine system. STT Emtec AB (pbl)
  • Page 38 STT SCRmarine 2019-05-15 Issue: 1.8 Installation Guideline Table 18. Wire installation chart 24VDC STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 39 Date Page 39 STT SCRmarine 2019-05-15 Issue: 1.8 Installation Guideline STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 40 STT SCRmarine 2019-05-15 Issue: 1.8 Installation Guideline Table 19. Wire installation chart 230VAC STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 41 Date Page 41 STT SCRmarine 2019-05-15 Issue: 1.8 Installation Guideline STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda Box 46, Njurundavägen 16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 42 60Ω. Should the CAN databus not be used by other nodes it may require external termination to be able to broadcast the data required by the DDS. Bus termination can be electronically enabled in 3 steps (HiZ=No termination, 120Ω or 60Ω). Contact STT Emtec AB for an updated dataset if CAN termination is required.
  • Page 43 24VDC installation a 10A fuse type B is recommended. In a 230VAC installation a 1A fuse is theoretically acceptable but the 3G1.5 ‘SUPPLY’ cable allows for a fuse in the practical range of up to 10A. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A...
  • Page 44 CAN and discrete sensors, i.e. some but not all required signals may be available on the CAN bus. Install all cables provided in the installation kit to make sure that all required signals are available to the DDS control system before commissioning. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A...
  • Page 45 Issue: 1.3 Installation Guideline 5 System operation The third section provides information on how to operate the SCRmarine control system, i.e. safe enabling/disabling and troubleshooting using the built-in diagnostic functions. 5.1 Routine operation The DDS control system does not require any day-to-day handling to operate normally.
  • Page 46 Table 23 – List of trouble codes serves as a guide for troubleshooting. Note! Some DTC’s are latched and need to be cleared before DEF dosing is re-enabled. (Latched DTC’s are marked ‘L’ in DTC list) STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A...
  • Page 47 System OFF. The current state is reflected on the Main menu screen. The system operating state is always displayed in the Main menu unless there are active trouble codes. NOx reduction is active when the state shows: ‘System OK’. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A...
  • Page 48 LCD operator and normal DEF dosing is inhibited Service Diagnostic Trouble Code(-s) active. DEF dosing disabled. required STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
  • Page 49 Previous Next X= On Activate Figure 55. LCD diagnose menu structure STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 50 Reverts to main menu after 30s if no key is pressed or by pressing key ← Note: in actuator test mode normal system operation (NOx reduction) is inhibited! STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A...
  • Page 51 Alarm relay Override alarm relay Pump priming Initiate the pump priming sequence DEF1 prs [mbar] STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 52 CAN communication 1. Check CAN wiring interrupted. Normally occurs 2. Check CAN termination with engine and NOx sensors. STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 53 Indicates a 2. Check DDU for internal blocked injection nozzle. blockage STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 54 Alarm reset Indicates how many times the DTC’s were reset STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 55 System disabled Release STOP switch on control cabinet Press START switch on control cabinet STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 – 2927 SE-862 02 NJURUNDA e-mail: info@sttemtec.com...
  • Page 56 See Appendix 13 – PC diagnostic tool manual for further information Figure 57. Example of monitoring software desktop STT Emtec AB (pbl) Tel: +46 (0)60-64 10 40 Head office: Njurunda BOX 46, Njurundavägen16A Fax: +46 (0)60 64 10 45 Org.nr: 55 62 05 –...
