Keeps drains flowing

DRAIN DEFENDER

USER'S GUIDE

Thank you for choosing DRAIN DEFENDER

. This guide will assist

you in proper installation and care of this innovative new product

that prolongs the proper flow of water through outdoor and indoor

pipe drains when leaves, grass, or other debris might otherwise lead

to clogging and expensive flooding. With proper maintenance,

DRAIN DEFENDER

can save you thousands of dollars and hours of

aggravation. Please follow the instructions in this guide to achieve

optimum performance.

WARNING: DRAIN DEFENDER

can pose a tripping hazard that can lead to serious injury. DRAIN

DEFENDER

is not intended for usage in areas where daily foot traffic is expected, or in areas

where the elderly or young children may be present.

WARNING: With proper care, DRAIN DEFENDER

clogs and flooded basements, while reducing your overall drain cleaning maintenance costs.

Failure to properly maintain your DRAIN DEFENDER

performance of the device. It's important to follow the maintenance and cleaning instructions

that follow to ensure proper operation and optimum performance.

INSTALLATION

DRAIN DEFENDER

does not require any tools to install.

Before installing Drain Defender

, remove any leaves, grass or other debris from the area around the

drain. Use a garden hose to check whether the drain flows well when debris is not present. Proper

flow can be impeded by clogging inside the drain pipe, root penetration, or other issues that can't be

improved by Drain Defender

. Contact a qualified professional if the water drains slowly.

Remove the outer SHELL and the inner STRAINER from the box. Be sure the center hub of the

STRAINER is pressed firmly onto the center post of the SHELL as shown:

SHELL STRAINER

can greatly reduce the chances of pipe drain

and the surrounding drain area can impair

3) Place the assembly over the drain, inserting the GUIDE PIN on the bottom of the

STRAINER into one of the drain holes or slots close to the center of the drain grate.

SHELL

EXISTING

DRAIN

GRATE

NOTE: It's acceptable for the DRAIN DEFENDER

slots in the drain grate close to the center of the grate, cut the GUIDE PIN off with cutters or scissors,

and position the assembly approximately over the center of the drain grate.

WARNING:

The STRAINER is made from a flexible material to accommodate uneven surfaces

surrounding the drain grate. DRAIN DEFENDER

significant steps or misalignment of the concrete or surrounding material caused by to cracking and

displacement of the surface.

CLEANING AND MAINTENANCE

WARNING:

Failure to properly maintain your DRAIN DEFENDER

can seriously impair performance, and lead to unwanted clogging and flooding. It's important to

follow these CLEANING AND MAINTENANCE instructions to ensure proper operation and optimum

performance.

1) Periodically remove the DRAIN DEFENDER

the SHELL by grasping the GUIDE PIN and pulling the STRAINER free.

2) Use a garden hose to spray any collected debris from the SHELL and the STRAINER.

If debris has hardened due to exposure and is difficult to remove, soak both the SHELL and

the STRAINER in water until softened, then spray as needed to remove from holes and slots.

Scrub as needed with a soft brush.

3) Sweep and remove any leaves, grass, pine needles, or any other debris that may have collected in the

drain area and any adjacent stairwell.

4) Press the STRAINER back onto the center post on the underside of the SHELL, and return the

assembly to service as described in the INSTALLATION section of this User's Guide.

NOTE: Over time, the STRAINER may no longer fit tightly to the SHELL, or may show signs of deterioration

that may lead to poor performance. Visit the draindefender.com website to order a replacement STRAINER.

Questions? E-mail us at support@draindefender.com

For information on our LIMITED WARRANTY, please visit www.draindefender.com

GUIDE

to be slightly off-center. If there are no holes or

performance may be seriously impaired if there are

and the surrounding drain area

assembly from the drain. Separate the STRAINER from
