Matermacc Irrigamatic P350 Manual For Use And Maintenance

Hide thumbs
Table of Contents

Advertisement

Quick Links

MANUAL
FOR USE AND
MAINTENANCE
SAN VITO AL TAGL. (PN) ITALY
SAN VITO AL TAGL. (PN) ITALY
TO
TO
P.I.
min
ON
START
OFF
reset
clear
IRRIGAMATIC
*FOR ENGLISH SYSTEM *m = FEET ( f IN DISPLAY )
*FOR ENGLISH SYSTEM *m = FEET ( f IN DISPLAY )
m
*
h
reg +/-
reg +/-
vlv +/-
vlv +/-
* m
h
GRAM
GRAM
P.F.
min
PRO
PRO
test bat
test bat
P
P
350
350

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Irrigamatic P350 and is the answer not in the manual?

Questions and answers

Related Manuals for Matermacc Irrigamatic P350

Summary of Contents for Matermacc Irrigamatic P350

  • Page 1 MANUAL FOR USE AND MAINTENANCE SAN VITO AL TAGL. (PN) ITALY SAN VITO AL TAGL. (PN) ITALY P.I. P.F. reg +/- reg +/- vlv +/- vlv +/- START GRAM GRAM reset test bat test bat clear IRRIGAMATIC *FOR ENGLISH SYSTEM *m = FEET ( f IN DISPLAY ) *FOR ENGLISH SYSTEM *m = FEET ( f IN DISPLAY )

  • Page 3: Table Of Contents

    CONTENTS General features Page 01 Introduction Page 02 Guarantee Page 02 Guarantee expiry Page 02 Description of the equipment Page 03 Carrying out the irrigation cycle Page 04 Starting-up Page 04 Switching the electronic console on Page 04 Initialization Page 04 End of start-up phase Page 04 Unwinding the tube...

  • Page 4: General Features

    1. GENERAL FEATURES Sprinkler trolley re winding speed adjustment (programmable from 5 to 250 m/h). Irrigation start time ( programmable up to max. 23 hours and 59 min). Pause when irrigation starts (programmable from 0 to 99 min). Pause when irrigation ends (programmable from 0 to 99 min). Unwound and rewound hose measurement (up to 999 meters).

  • Page 5: Introduction

    The manual contents and drawings are updated on printing date and refer to the features of the console they are supplied with. Matermacc s.r.l. reserves the right of updating and/or modifying them without prior notice.

  • Page 6: Description Of The Equipment

    4. DESCRIPTION OF THE EQUIPMENT The IRRIGAMATIC P350 console is equipped with 11 keys by which the operator programs the system according to their own requirements and with a display sending a series of information. ON/OFF switching key START Working cycle start Irrigation start time P.I.

  • Page 7: Carrying Out The Irrigation Cycle

    5. CARRYING OUT THE IRRIGATION CYCLE For a correct irrigation procedure, we reccomend executing the various phases in the right order as described below. PHASE DESCRIPTION Switch console on. (see par. 6 - page 04) Unwind the tube. The console will measure and display the meters of tube being unwound.

  • Page 8: Unwinding The Tube

    7. UNWINDING THE HOSE The hose shall be unwound at the end of the starting-up phase and before pressing the key to start the working cycle. START END-OF-UNWINDING ADVISING (IF REQUIRED) During the unwinding the console can receive a signal corresponding to the programmed quantity of tube being unwound.

  • Page 9: Programming

    8. PROGRAMMING START We recommend to program at the end of the start-up phase and before pressing key to start the working cycle. However the set values can also be modified while executing the working cycle, always by following the same input procedure 8.1 PROGRAMMING THE WORKING CYCLE NOTE The values that were modified when the working cycle is in process (IRR)
  • Page 10 8.1.2 PROGRAMMING THE INITIAL PAUSE It's possible to set the initial pause (without rewinding the hose) up to max. 99 minutes. Recall the initial pause. P.I. Press key Set the minutes. Press key without releasing it and then press keys GRAM GRAM to set the required minutes (for ex.

  • Page 11: Programming The User's Menu

    8.2 PROGRAMMING THE USER’S MENU Further minor functions have been added to a menu, access to which is possible both during the programming phase and at work. Access to the user's menu. GRAM GRAM When the console is on press on keys at the same time.
  • Page 12 Set the hours. Press key to move forward and display the clock time GRAM GRAM Press key without releasing it and then press keys modify the displayed hour. Set the minutes. Press key to move forward and display the hour. the minutes. Press key without releasing it and then press keys...

  • Page 13: Displaying The Estimated End-Of-Irrigation Time

    8.3 DISPLAYING THE EXPECTED END-OF-IRRIGATION TIME Press key to know when the end-of-irrigation is expected. This time is calculated by the console by adding up the initial pause, the final pause and the time needed to carry out the cycle, based on the unwound meters and on the rewinding speed that has been programmed.

  • Page 14: Working Cycle

    9. WORKING CYCLE 9.1 WORKING CYCLE START After unwinding the hose and entering the programming data correctly, start the working cycle by pressing key START 9.2 CARRING OUT THE WORKING CYCLE The console signals to the operator that the working cycle is starting. Irrigation start time (only if programmed) The irrigation start time is displayed until it is reached.

  • Page 15: Specials Visualisations

    9.4 SPECIAL VISUALISATIONS 9.4.1 VISUALISATIONS WITH END-OF-IRRIGATION LIMIT TIME If during the execution of the working cycle the end-of-irrigation limit time function is active (see paragraph 11.3 page 15), the console signals this condition as follows: Clock. A small "o" blinks between the hours and the minutes Speed.

  • Page 16: End Of Working Cycle

    10. END OF WORKING CYCLE The end-of-work procedure starts: by activating the end-of-rewinding sensor (if mounted on the irrigator) End Rewind In this case when the sensor is activated, the console displays when reaching the programmed meters to end the irrigation before winding the whole hose (see par.

  • Page 17: Special Functions

    11. SPECIAL FUNCTIONS 11.1 END-OF-UNWINDING ADVISING During the unwinding the console may give you a signal corresponding to a programmed quantity of hose unwound. To get this signal, it is necessary to equip the installation with an advise signal (blinking, siren, radio, etc.) controlled by the relay contact available on the console (terminal M10).

  • Page 18: End-Of-Irrigation Limit Time

    11.3 END-OF-IRRIGATION TIME LIMIT This function allows to establish the time within which irrigation should be ended. Any considerations concerning the application of this function should be related to the indication of the end-of-irrigation time, displayed by pressing key (see par. 8.3 page 10). For this reason, it is important to set all programming values correctly.

  • Page 19: Sensors Test

    Should the operation of the various connected sensors not be displayed, check the installation and the integrity of cables, connections, sensors and repeat the test. If the result is still negative contact your dealer or MATERMACC servicing center. Pag.16 REV 0/00...

  • Page 20: Display Messages

    13. DISPLAY MESSAGES 13.1 OPERATING MESSAGES Stop Press0 This message can only be displayed if the pressure switch is connected to the console. It shows the pressure in the hose has fallen below the pressure switch calibration value. The pressure switch is only checked during the working cycle. When there is not enough pressure in the hose, the cycle is interrupted.
  • Page 21 Stop Trol? If during the working cycle the rewinding speed equal to zero for more than 3 IRR ---m/h minutes, this message will be displayed. This is the time needed by the console to Stop Trol? Stop Trol? establish that the trolley is stopped.Therefore the speed adjustment motor is controlled automatically to reach the programmed speed.

  • Page 22: Error Messages

    13.2 ERROR MESSAGES Err Mot This error message is displayed when there is a problem with the speed adjustment motor or the end-of-work motor. The Err Mot message always comes together with a second message that identifies the cause of the problem better. In particular: Short circuit of speed adjustment motor Reg Sc...
  • Page 23 Err Hc It is displayed when pressing key and the duration of the working cycle has been calculated in over 24 hours. NOTE This message does not jeopardize the console operation in any way. When the cycle lasts less than 24 hours , press key to obtain the information concerning the arrival time ReWind End Err...

  • Page 24: Motor Drive Messages

    13.3 MOTOR DRIVE MESSAGES Reg+ It means that the console is controlling the adjustment motor to increase the rewinding speed. Reg- It means that the console is controlling the adjustment motor to reduce the rewind speed. It means that the adjustment motor has reached the end of stroke position at lowest speed.

  • Page 25: Extra Functions

    14. EXTRA FUNCTIONS Battery test At any time you can know if the battery charge is still good by pressing key at the same time. The system would display the voltage (in Volts) of the battery supplying power to the console (for ex. 13v). Reset This operation should be carried out if you wish to start a new cycle with the same programmed values.

  • Page 26: Manual Motor Control

    15. MANUAL MOTOR CONTROL At any time you can control the motors connected with the IRRIGAMATIC console manually. 15.1 SPEED ADJUSTMENT MOTOR CONTROL Increase speed P.I. Press keys at the same time. The speed adjustment motor is controlled by the console intermittently. During the motor rotation Reg+ is displayed.
  • Page 27 EC DECLARATION OF CONFORMITY 98/37/Matermacc S.r.l. Viale Ponte Rosso 35 33078 SAN VITO AL TAGLIAMENTO (PN) ITALIA HEREBY DECLARES that IRRIGAMATIC Model P350 Serial n° Tipy Produced by Matermacc s.r.l. San Vito al Tagliamento (PN) Italia In _ _ _ _ complies with these safety and health requirements demanded by EC directives 98/37/ and 89/336 as further modified.
  • Page 28 Viale Ponte Rosso 33078 San Vito Al Tagliamento (PN) I Tel 0434/85267 - Fax 0434/85517 E-MAIL MATERMACC@TIN.IT...
