Summary of Contents for Aversix EVO-100 Series
- Page 1 User Manual Industrial Display Modules EVO-100 Series...
-
Page 2: Table Of Contents
Contents EVO-100 Series Display Module User Manual Prefaces……………………………………………………………………………………….…03 Revision……………………………..……...………………………………………………...……………………………..03 Copyright and Trademarks Notice…………………………………………….…..……………………………..03 Disclaimer……………………………………………….……………………………………………………………………03 Declaration of Conformity…………………………..……………………………………..…………………………03 Technical Support and Assistance………………….…………….…………………………………………….…03 Safety Instructions……………….………………………….……………….………………………………….………03 Packing List….……………………………………………….…….……………………….…………………………….…04 Ordering Information….………………………………………….………………………….…………..……………05 Chapter 1 Product Introductions…………………………….………………………06 1.1 Overview…………………………………..………….…………………………………………………….…………07 1.1.1 EVO-110(A)(T)…………………..………….………………………………………..……………………08 1.1.2 EVO-112(A)(T)…………………..………….…………………………………………………..…………09 1.1.3 EVO-115(A)(T)…………………..………….…………………………………………..…………………10 1.1.4 EVO-117(A)(T)…………………..………….……………..………………………………………………11 1.1.5 EVO-119(A)(T)…………………..………….………………………..……………………………………12... -
Page 3: Prefaces
This user’s manual is for informational purposes only and is subject to change without prior notice. It does not represent commitment from Aversix Inc. This product might include unintentional typographical or technical errors. Aversix will periodically correct such erroneous files and incorporate these corrections into the new version of the file. -
Page 4: Packing List
EVO-100 Series Display Module User Manual Package List EVO-110(A)(T) EVO-112(A)(T) Item Description Q’ty Item Description Q’ty EVO-110 Series Display Module EVO-112 Series Display Module Panel Mount Kit Panel Mount Kit EVO-115(A)(T) EVO-117(A)(T) Item Description Q’ty Item Description Q’ty EVO-115 Series Display Module... -
Page 5: Ordering Information
EVO-100 Series Display Module User Manual Ordering Information Model No. Product Description 10.4" (4:3) XVGA Single-Point Projected Capacitive Touch Display EVO-110A Module 10.4" (4:3) XVGA Ten-Point Projected Capacitive Touch Display EVO-110T Module 12.1" (4:3) XVGA Single-Point Projected Capacitive Touch Display... -
Page 6: Chapter 1 Product Introductions
EVO-100 Series Display Module User Manual Chapter 1 Product Introductions... -
Page 7: Overview
EVO-100 Series Display Module User Manual 1.1 Overview EVO-100 Series is an evolved projected capacitive touch display module, equipped with Aversix Display Conversion Device (DCD) Technology and combined with a 10.4" ~ 24" LCD. It can be used with AVD/AVP Series products according to the usage requirements. -
Page 8: Evo-110(A)(T)
EVO-100 Series Display Module User Manual 1.1.1 EVO-110(A)(T) Key Features • 10.4” TFT XGA 4:3 LCD with Projected Capacitive Touch • -20°C to 70°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 9: Evo-112(A)(T)
EVO-100 Series Display Module User Manual 1.1.2 EVO-112(A)(T) Key Features • 12.1” TFT XGA 4:3 LCD with Projected Capacitive Touch • -20°C to 70°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 10: Evo-115(A)(T)
EVO-100 Series Display Module User Manual 1.1.3 EVO-115(A)(T) Key Features • 15” TFT XGA 4:3 LCD with Projected Capacitive Touch • -20°C to 70°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 11: Evo-117(A)(T)
EVO-100 Series Display Module User Manual 1.1.4 EVO-117(A)(T) Key Features • 17” TFT SXGA 5:4 LCD with Projected Capacitive Touch • -20°C to 70°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 12: Evo-119(A)(T)
EVO-100 Series Display Module User Manual 1.1.5 EVO-119(A)(T) Key Features • 19” TFT SXGA 5:4 LCD with Projected Capacitive Touch • -10°C to 50°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 13: Evo-W115(A)(T)
EVO-100 Series Display Module User Manual 1.1.6 EVO-W115(A)(T) Key Features • 15.6” TFT FHD 16:9 LCD with Projected Capacitive Touch • -20°C to 70°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 14: Evo-W121(A)(T)
EVO-100 Series Display Module User Manual 1.1.7 EVO-W121(A)(T) Key Features • 21.5” TFT FHD 16:9 LCD with Projected Capacitive Touch • -10°C to 60°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 15: Evo-W124(A)(T)
EVO-100 Series Display Module User Manual 1.1.8 EVO-W124(A)(T) Key Features • 24” TFT FHD 16:9 LCD with Projected Capacitive Touch • -20°C to 70°C operating temperature • 1x Remote OSD Connector • 2x 2W internal speakers • Designed with aluminum die-casting front frame •... -
Page 16: Mechanical Dimensions
EVO-100 Series Display Module User Manual 1.2 Mechanical Dimensions 1.2.1 EVO-110(A)(T) Unit: mm 1.2.2 EVO-112(A)(T) Unit: mm... -
Page 17: Evo-115(A)(T)
EVO-100 Series Display Module User Manual 1.2.3 EVO-115(A)(T) Unit: mm 1.2.4 EVO-117(A)(T) Unit: mm... -
Page 18: Evo-119(A)(T)
EVO-100 Series Display Module User Manual 1.2.5 EVO-119(A)(T) Unit: mm 1.2.6 EVO-W115(A)(T) Unit: mm... -
Page 19: Evo-W121(A)(T)
EVO-100 Series Display Module User Manual 1.2.7 EVO-W121(A)(T) Unit: mm 1.2.8 EVO-W124(A)(T) Unit: mm... -
Page 20: Chapter 2 Display Module Controls
EVO-100 Series Display Module User Manual Chapter 2 Display Module Controls... -
Page 21: Display Module Function
EVO-100 Series Display Module User Manual 2.1 Display Module Function 2.1.1 POWER button Press to power-on or power-off the monitor (EVO-100 / AVD Series) Press to backlight-on or blacklight-off the display module (EVO-100 / AVP Series) 2.1.2 MENU (ENTER) button Press to view the OSD menu. -
Page 22: Osd Operation
EVO-100 Series Display Module User Manual 2.2 OSD Function 2.2.1 Luminance • Brightness Adjust the luminance level (0~100) of the screen. • Contrast Adjusts the contrast level (0~100) of the screen. • Gamma This item allows user to on or off the Gamma function. -
Page 23: Picture
EVO-100 Series Display Module User Manual 2.2.2 Picture • Phase Adjust the internal signal phase of the monitor. • Clock Adjust the internal sampling clock rate of the monitor • H. Position Adjusts the position of the screen image left and right. -
Page 24: Osd Settings
EVO-100 Series Display Module User Manual 2.2.4 OSD Settings • Horizontal Changes the viewing position of the OSD menu to the left or right area of the screen. • Vertical Changes the viewing position of the OSD menu to the upper or lower area of the screen. -
Page 25: Chapter 3 System Setup
EVO-100 Series Display Module User Manual Chapter 3 System Setup... -
Page 26: Connect Pc Or Touch Monitor Module With Evo Series Display Module
1. Hold computer module or monitor module with its connector facing towards the connector on the back of EVO-100 series display module. 2. Press computer module or monitor module down to ensure the two modules are firmly connected. - Page 27 EVO-100 Series Display Module User Manual 3. Lock the below 6 screws.
