Summary of Contents for Moravian Instruments DataLab LCD 15
- Page 1 DataLab LCD 15-T 15'' LCD flat panel monitor with touch screen...
- Page 2 All information furnished by Moravian Instruments is believed to be accurate. Mora- vian Instruments reserves the right to change any information contained herein without notice. DataLab devices are not authorized for and should not be used within Life Support Sys- tems without the specific written consent of the Moravian Instruments.
-
Page 3: Table Of Contents
Content DataLab LCD 15 / 15-T......................4 Monitor description......................5 Monitor setup........................5 Connectors........................6 Control panel........................6 On-screen menu functions....................7 Top level menu items.......................7 Touch screen........................8 Monitor mounting hole.....................9 External control buttons....................10 Technical specification....................11 Ordering codes......................11... -
Page 4: Datalab Lcd 15 / 15-T
DataLab LCD 15 / 15-T LCD flat panel monitor with touch screen... -
Page 5: Monitor Description
DataLab LCD 15 / 15-T Monitor description Complete monitor package contains the following parts: flat panel monitor ● cable for 230 V AC power supply ● analog VGA cable 1,8 m long ● USB data cable 2 m long (only for monitors equipped with touchscreen) ●... -
Page 6: Connectors
DataLab LCD 15 / 15-T Connectors Following connectors are available: power connector for 230 V AC with fuse. ● analog VGA connector (CANNON 15 Z 3R) ● external control buttons connector (CANNON 9 Z) ● touchscreen USB-B connector (only for monitors equipped with touchscreen). -
Page 7: On-Screen Menu Functions
DataLab LCD 15 / 15-T Quick brightness adjustment: Press >.button Use < and > buttons to adjust brightness from 0 (min) to 100 (max). Press Exit button to keep selected brightness On-screen menu functions On-screen menu can be opened by pressing the Enter. button. Requested item can be se- lected by <... -
Page 8: Touch Screen
DataLab LCD 15 / 15-T Touch screen The flat panel monitor is optionally equipped with a touch screen. Touch screen panel works similarly to standard computer mouse with USB interface (it is connected to the com- puter through standard USB cable). To ensure proper function of touch screen make sure... -
Page 9: Monitor Mounting Hole
DataLab LCD 15 / 15-T Monitor mounting hole DataLab LCD 15-T is designed to be mounted to a panel. Maximal panel thickness is 10 mm. Dimensions are in millimeters. Remark: Usually 4 screws on the sides are enough to hold the monitor firmly in place. If the mounting panel is rather thin, two another screws on the top and bottom sides can be also used. -
Page 10: External Control Buttons
DataLab LCD 15 / 15-T External control buttons If the monitor control buttons are not reachable and it is desired to change monitor setting, it is possible to connect external buttons to the monitor through the EXT connector. The EXT connector provides access to contacts of all control buttons, as well as signal LED. In-... -
Page 11: Technical Specification
Width × Height × Depth = 400 × 350 × 70mm Weight 5,3 kg Protection IP65 ) Touch panel is optional component.. ) Valid for front cover. Ordering codes DL–LM15T DataLab LCD 15T 15" LCD monitor with touch screen DL–LM15 DataLab LCD 15 15" LCD monitor...
