The wireless-mini insert module ITL-2300 is ideal for wireless switching
on/off up to 2300 watt.
To be installed in the power supply to lamps, so they can be switched on
and off using the light switch as well as remotely.
Thanks to its compact size, it can be mounted directly behind a light
switch in the flush-mounted box.
It's also easy to operate as part of a toggle switch.
Integrated automatic switch off from 0/1 min. /10 mins/1 h/4 h to allow
versatile applications (Fig.1).
All teaching transmitters
and all transmitters for scene switching
made by intertechno can be used.
Mounting (only to be carried out by a qualified electrician):
1.) Turn off the fuse.
2.) The connections must be configured as shown in figures 2a and 2b
(for toggle switches).
Encoding (Fig. 3)
3.) Turn on the fuse again.
The LED will shine for 10 seconds, this means it is ready for operation.
4.) Briefly press the learn button (L) on the module with a pointy object
(e.g. paper clip, ballpoint pen).
The LED will flash.
5.) Press the ON button on the transmitter.
The LED will flash 3x as confirmation.
The encoding is now complete.
If no signal is transmitted within 12 seconds, the learning process is
automatically aborted.
A total of 32 different codes or teaching transmitters (no letter and
number encoding) can be taught in.
The first code will be deleted if more codes are entered.
The encoding remains saved even after a power cut.
Using several wireless receivers opens up many switching options such
as individual and group switching.
