Miller Raptor Pairing Instructions

Raptor Remote & R260 Master

How to Pair

Pairing is a procedure used to ensure that only compatible transmitters and receivers are allowed to

communicate for the purpose of controlling equipment. Every transmitter and receiver has a unique

device id, and these ids, along with other information, must be exchanged and verified before

equipment control is possible.

How do you tell if your transmitter or receiver is already paired? If you power up the transmitter and it is

not paired to any receiver, it will display the following:

If you power up the receiver and it is not paired to any transmitter, it will display the following LED

pattern (LEDs on solid):

For safety reasons, pairing is a manual operation, i.e. pairing never occurs without direct operator

intervention. Pairing is primarily done from the transmitter, but the receiver must also be put into a

special 'Pairing' mode. There are two ways to do this:

1. Remove the receiver's housing and press the TEACH button while the receiver is powered up, or

2. Move the transmitter close enough to the powered-up receiver (1-2") so one of the permanent

magnets in the transmitter housing can trigger a magnetic switch in the receiver. In the receiver, the

magnetic switch is behind the Omnex or Eaton logo. In the transmitter, the two magnets are located

inside the upper rear of the transmitter housing, immediately behind the magnet targets.

to use the top magnet on the yellow T110 remote than trying to use the Raptor remote magnets.

NOT PAIRED

STATUS

I/O

LINK

It is easier

Table of Contents

Need help?

Do you have a question about the Raptor and is the answer not in the manual?

Page 1 Omnex or Eaton logo. In the transmitter, the two magnets are located inside the upper rear of the transmitter housing, immediately behind the magnet targets. It is easier to use the top magnet on the yellow T110 remote than trying to use the Raptor remote magnets.
Page 2 Pairing Procedure (over radio) 1. Turn on the receiver. 2. With the transmitter off: press and hold down the lower left-hand soft button, then press/release the power button. When the following screen appears, release the soft button: Pairing 1. Power up receiver 2.
Page 3 5. If pairing is successful, the receiver will automatically reset itself and should display the following LED pattern: STATUS LINK and the transmitter will display the following (in this example, the transmitter has paired to a receiver that has been configured with the name “BluePumperTruck”: Pairing 1.
Page 4 Pairing Rules 1) You cannot put the receiver into Teach mode if it is linked to a transmitter. 2) You can only pair one transmitter with one receiver. If you pair a second transmitter with the receiver, the receiver will lose the first transmitter’s pairing information. 3) If the firmware, application or configuration file is updated in the transmitter or receiver, you will have to pair again.
