Dust
Model DE Series
Collector
Twin-Vac
Shop
Owner's Manual
WARNING
This equipment must not be operated without complete
observance of the safety rules and grounding and power
hook-up instructions. Not observing this information can
result in electrical shock, serious physical injury or damage
to the equipment.
Advertisement
Summary of Contents for RYVAC DE Series
- Page 1 Dust Model DE Series Collector Twin-Vac Shop Owner's Manual WARNING This equipment must not be operated without complete observance of the safety rules and grounding and power hook-up instructions. Not observing this information can result in electrical shock, serious physical injury or damage...
- Page 2 Specifications DE-924-AL/EL MODEL DE-115-AL/EL DE-217-AL/EL 115/230, 1Φ Input Voltage (VAC) 115/230, 1Φ 115/230, 1Φ Power Consumption (KW) 20/10 Amperage (A) 15/7.5 17/8.5 20, 12/16 AWG Power Cable Length (FT) 20, 16/18 AWG 20, 14/18 AWG 200 (5.7 M Max Air Flow (CFM) 160 (4.5 M 180 (5.1 M 95 (2400 mm)
- Page 3 DE-217 ITEM NO DE-115 DE-924 DESCRIPTION RV-15029 RV-10929 RV-10029 Shaking Hanger RV-15021 RV-15021 RV-10021 Motor Cover RV-10056 RV-10056 RV-10056 Cart Handle Assy RV-10032 RV-10031 RV-10033 Inlet Hose Adapter RV-15025 RV-10025 RV-10940 Dust Bucket 3"Dia 2"Dia Swivel H.R. Caster 14/3 SJT x 20' 12/3 SJT x 20' 16/3 SJT x 20' Standard Power Cable...
- Page 4 Safety Precautions 1. Grounding - This equipment must be grounded. Make sure that the plug is con- nected to a 3-pole grounded outlet. 2. Power Hook-up - This equipment is designed to be operated from a source of single phase power. When an extension cord is needed, the extension cord must be of the same or larger guage as the supplied power cable to prevent loss of power or overheating of the cable.
- Page 5 2. Grounding and Power Hook-up - The plug must be connected to a properly grounded outlet. Improper connection of the equipment can result in a risk of an electrical shock. Please observe the following figure for hookup to either a standard grounded outlet or for use of the grounding tab on a standard adapter.
-
Page 6: Limited Warranty
Unscrew the black knob on the top of the shaker bar. Remove the dust bucket as previously instructed. Unscrew 3 nuts of RE-115AL or 4 nuts of RE-217AL from the filter plate (located inside from where the bucket was removed.) Slide down the entire filter plate, filter assembly and shaking bar as one piece together.
