HARBIN ROPV INDUSTRY DEVELOPMENT CENTER
ROPV R80 S Series User Manual
For Use with the Following ROPV Pressure Vessel Models:
R80 600S
R80 800S
R80 1000S
R80 1200S
Headquarters
Harbin ROPV Industry Development Center
100 Hongqi St.
Xiangfang District
Harbin, China 150036
Tel: +86-451-5515-5144
Fax: +86-451-5515-5124
Email:
ropv@ropv.com.cn
Website:www.ropv.com.cn
ROPV R80 S Series Manual
August 2005B
Advertisement
Summary of Contents for ROPV R80 S Series
- Page 1 HARBIN ROPV INDUSTRY DEVELOPMENT CENTER ROPV R80 S Series User Manual For Use with the Following ROPV Pressure Vessel Models: R80 600S R80 800S R80 1000S R80 1200S Headquarters Harbin ROPV Industry Development Center 100 Hongqi St. Xiangfang District Harbin, China 150036...
- Page 2 2 – 12 (less than 30 minutes) General Warning – High Pressure Membrane Housing ROPV Pressure Vessels are designed to provide safe operation over a long service life if properly installed, operated, and maintained. The vessel may cause loss of life, severe bodily harm, or property damage if not correctly installed, operated, or maintained.
- Page 3 • These guidelines are subject to change. Please check with ROPV to ensure that the User Manual is the latest version for the vessel model being used. • Mount vessel using strap/saddle hardware provided and span recommended in the engineering drawing.
- Page 4 Step 6 Remove the Head Assembly with One of the Following Techniques ROPV Head Removal Tools – A set of head removal tools is available from ROPV. While not necessary for head removal, they have proven an effective and easy way to remove the vessel head without causing any damage to the vessel.
- Page 5 Alternative Head Removal – It is possible to remove the head assembly without the ROPV head removal tools. A 1” NPT Male threaded piece of PVC (or similar material) pipe should be threaded into the head permeate port to hand tightness. Pull the pipe outward to remove the head.
- Page 6 After removing the locknut, the bearing plate and sealing plate can be separated. Step 4 Clean All Components – All components should be cleaned with a mild soap ROPV R80 S Series Manual August 2005B...
- Page 7 Clean water should be used to clean the area after sanding. Any extemporaneous matter can be removed with a soft cloth, soapy water, and a clean water flush. Damaged vessels should not be used under any circumstances. Picture of Disassembled Head Components ROPV R80 S Series Manual August 2005B...
- Page 8 Please see Step 6 above for additional information about cleaning head components. Scratched or damaged components should be replaced with ROPV supplied replacement components. All o- rings should be carefully inspected for signs of damage. It is recommended that all o- rings be replaced during each complete servicing of the vessel.
- Page 9 Step 7 Install Head O-ring – All o-rings should be coated with a thin layer of glycerine before installation. Seat the head o-ring into the groove on the outside diameter of the head. Complete Head Assembly with Adapter ROPV R80 S Series Manual August 2005B...
- Page 10 ROPV R80 S Series Manual August 2005B...
- Page 11 Step 6 Pressurize System Step 7 Inspect for Leaks – All connections should be free from leaks. Do not operate leaking vessels. ROPV R80 S Series Manual August 2005B...
- Page 12 -4 and longer vessels have a third strap/saddle assembly, to be installed at the center point of the vessel. Tighten straps to hand tightness plus one turn. Manifold span should be greater than vessel span to allow for vessel growth under pressure. ROPV R80 S Series Manual August 2005B...
- Page 13 R80 S Series Parts List Part Name R80600S R80800S R801000S R801200S Shell 8005.1-7 8006.1-7 8007.1-7 8007.8-14 Bearing Plate 8009 Sealing Plate 8010.2 Plug 8013 Permeate Port 8064.3 Permeate Port 8014.1 Locknut Feed/Conc. Port 80051 Retaining Ring Feed/Conc. Port 8018.1 8018.2 8018.3...
- Page 14 If the Product is found by ROPV to be defective under the terms of this warranty, ROPV will perform one of the following at its option: 1. supply a substantially similar replacement part based on FOB factory terms.
- Page 15 ROPV R80 S Series Manual August 2005B...
- Page 16 ROPV R80 S Series Manual August 2005B...
- Page 17 ROPV R80 S Series Manual August 2005B...
- Page 18 ROPV R80 S Series Manual August 2005B...
