Bluetooth Version:
Bluetooth Frequency:
Bluetooth distance:
Support music codec
Charging time:
Standby time:
Music play time
Battery:
SNR:
Charging plug:
Charging voltage:
Speaker power:
Net weight:
Dimension:
User Manual
BS-39B Bluetooth Soundbar Speaker
V4.2+BR+EDR+BLE
2402MHz-2480MHz
10M
MP3,WAV,WMA.FLAC,APE
5 hours
120 hours
upon to 5.5 hours
3.7V/4000mA
－ 80db
Micro USB
DC 5V/2A
5W×2
680g
248×102×57mm
Advertisement
Table of Contents
Summary of Contents for Raitron BS-39B
- Page 1 User Manual BS-39B Bluetooth Soundbar Speaker Bluetooth Version: V4.2+BR+EDR+BLE Bluetooth Frequency: 2402MHz-2480MHz Bluetooth distance: Support music codec MP3,WAV,WMA.FLAC,APE Charging time: 5 hours Standby time: 120 hours Music play time upon to 5.5 hours Battery: 3.7V/4000mA SNR: － 80db Charging plug:...
- Page 2 Graphic illustration Function Indicator 1. Power on/off button and mode switch button 2. Music play/pause button, Time settings, Alarm settings, Call button 3. Volume down/ Time adjustment decrease 4. Volume up/ Time adjustment increase 5. Previous song 6. Next song...
- Page 3 7. Charging indicator light 8. DC 5V Micro USB charging port 9. TF card reader 10. USB socket 11. Optical input socket 12. 3.5mm audio input socket 13. RCA input socket 14. LED display screen 15. Infrared receiver (remote receiver) 16.
- Page 4 phone player and play songs. Due to different brands of mobile phone and Bluetooth versions, the searching and pairing time will be various. Under normal circumstances, it only takes 30 seconds. If the pairing password is needed, please type “0000” on the cell phone.
- Page 5 TV Mode 1. Connect the RCA plug to the speaker, and connect the RCA plug to the TV RCA audio output socket. 2. Turn on the speaker(now in the clock mode),then press the on/off button to switch the mode to RCA mode. 3.
- Page 6 or 5V/2A power source. The indicator light will turn red while charging. When the battery is full charged, the red indicator light will turn off. Wireless Charge 1. Place the phone which with wireless charging function on the wireless charging area of the speaker.
- Page 7 Common problems and solving method 1. Connecting for many times still unsuccessful? (1) Check the speaker whether is on Bluetooth searching mode. (2) If there are too many Bluetooth receivers around, it may cause the difficulty on searching. Please turn off other Bluetooth receivers. (3) Open the Bluetooth settings on your phone, cancel pairing and reconnect.
