Summary of Contents for Right On TS-794R
- Page 1 Revision: B Box Rack shown on LCI-8791p Multi-Sport Trailer also works with LCI-879p Dolly Trailer TS-794R Box-Sport Rack Approxim ate AssemblyTime Shipping Weight: 35 lbs 1/2 hour Max Load Capacity: 300 lbs Parts List & Assembly Instructions...
-
Page 2: Exploded Parts View
The tools and supplies you will need: - Box wrenches (1/2”, 9/16”, 17mm) - Sockets (1/2”, 9/16”, 17mm) - Clear or Black Silicone Caulk (not included) *Identify and layout all bolts and fasteners before starting assembly* EXPLODED PARTS VIEW... -
Page 3: Parts List
Rack Parts Hardware No. Item No. Item Front Vertical Bracket Bolt 5/16 x 2" Rear Vertical Bracket Bolt 5/16 x 3" Front Foot Bracket Nyloc Nut 5/16" Rear Foot Bracket Bolt 3/8 x 4" Fore-Aft Bracket Bolt 3/8 x 5" Crossbar Nyloc Nut 3/8"... -
Page 4: Assembly Steps
STEP 2 STEP 2: Disassemble 3/8” x 2.5“ Bolts (qty 2) that pass through the front Fender hole and Side Rails of the trailer - these will not be reassembled. Place the Rear Foot Bracket (4) in position shown. Assemble the 3/8” x 4“... - Page 5 STEP 4 STEP 4: Assemble the Front Vertical Bracket (1) into the Fore-Aft Bracket (5) and slide down onto the Front Foot Bracket (3) and Rear Vertical Bracket (2). Use (qty 5) 5/16” x 2” Bolts, and (qty 5) Nuts to fasten together finger tight.
- Page 6 STEP 5: Assemble the top 2 Crossbars (6) using (qty 4) 5/16” x 2“ Bolts (A). The bolts will screw into weld nuts that have been installed in the Front Vertical Brackets (1) and the Fore -Aft Brackets (5). Assemble the bottom 2 Crossbars (6) using (qty 4) 5/16”...
