Summary of Contents for Plugreen PGM-200P-230
- Page 1 Installation and Operations Manual Plugreen Solar Micro-Inverter Systems PGM-200P-230 PGM-230P-230 PGM-260P-230 Contact Information Plugreen Corporation, Laattakatu 13, 08150 Lohja, Finland Phone : +358 40 1525086 www.plugreen.com support@plugreen.com Passionately Powered...
-
Page 2: Table Of Contents
Step 3 - Lay the AC common cable along the rack using mounting hooks Step 4 - Connect the individual micro inverter on the common cable Step 5 - Ground the system using suitable copper wire Step 6 - Completing the Plugreen Installation Map and Connecting the PV Modules Commissioning Troubleshooting... -
Page 3: Important Safety Information
Connect the Plugreen Solar micro-inverter to the electrical utility grid only after receiving prior approval from the utility company. § Be aware that the body of the Plugreen Solar micro-inverter is the heat sink and can reach a temperature of 80 C. To reduce risk of burns, do not touch. §... -
Page 4: Plugreen Solar Micro-Inverter System
AC power, connect Ethernet cable between the units and your broadband router or modem. Once you install the Communication Gateway unit, it automatically starts communicating with the centralized web server. Please log in to the data monitoring web server though Plugreen webpage to understand the data logging systems and displays. -
Page 5: Plugreen Solar Micro-Inverter Installation
3 Plugreen Solar micro-inverter Installation 1 Plugreen Solar micro-inverter System PV systems using Plugreen Solar micro-inverters are simple to install. Each Solar micro-inverter quickly mounts on the PV racking, directly beneath each PV module. Low voltage DC wires connect from the PV module directly to the co-located solar micro-inverter, thus eliminating the risk of personnel exposure to lethal 600Vdc power. -
Page 6: Installation Procedure
WARNING: Do not connect Plugreen Solar Micro Inverter to a off grid like Inverter, UPS or Generator Copyright Plugreen Corporation. 2011 1-00001 REV 1... -
Page 7: Step 1 - Install The Ac Branch Circuit Junction Box
WARNING : Use electrical system components approved for wet locations only. § Connect the open wire end of the Plugreen AC Common Cable into the junction box using an appropriate gland or strain relief fitting. § Route the continuous Grounding Electrode Conductor (GEC) through the grounding clamp of each solar micro-inverter. -
Page 8: Step 6 - Completing The Plugreen Installation Map And Connecting The Pv Modules
You can use the blank map in the Appendix to record solar micro-inverter placement for your system. When your map is complete, send it to Plugreen as described below. Plugreen then uses this information to provide you with detailed information about the performance of your PV system and to allow you to see a graphic representation of your PV system on the Plugreen ‘Insight’, a web-based monitoring... -
Page 9: Commissioning
4 Commissioning WARNING: Connect the Plugreen Solar micro-inverter to the electrical utility grid only after receiving prior § approval from the utility company. § Only qualified personnel must connect the Plugreen Solar micro-inverters to the Utility grid § Ensure that all AC and DC wiring is correct and none of them are damaged §... -
Page 10: Troubleshooting
PV system does not operate correctly: WARNING : Do not attempt to repair the Plugreen Solar micro-inverter; it contains no user- serviceable parts. If it fails, please contact Plugreen customer service to obtain an RMA number and start the replacement process. >... -
Page 11: Disconnecting The Plugreen Solar Micro-Inverter From The Pv Module
If the problem persists, please call to customer support at Plugreen. STEP 6 WARNING: Do not attempt to repair the Plugreen Solar micro-inverter; it contains no user- serviceable parts. If troubleshooting methods fail, please return the solar micro-inverter to your distributor for maintenance. -
Page 12: Technical Data
PV module configurations. Be sure to verify the voltage and current specifications of your PV module match with those of the solar micro-inverter. For more information, refer to the Plugreen website (www.Plugreen.com) for a list of approved PV module racking systems and PV modules. -
Page 13: Voltage And Frequency Limits For Utility Interaction
6 Technical Data Plugreen Solar micro-inverter - AC Operating Parameters Parameter/Model Unit Typical Maximum AC output Power (-40 to +65 Deg C) PGM200/230/260 200/230/260 Output power factor 0.95 0.99 Nominal AC output voltage range PGM200/230/260 Vrms Maximum AC output current PGM200/230/260 .85/1/1.1... -
Page 14: Appendix
Plugreen. Before requesting the RMA, however, the customer should contact Plugreen technical support representative to evaluate and troubleshoot the problem while the Plugreen Solar Micro-inverter is in the field, since many problems can be solved in the field. Copyright Plugreen Corporation. 2011 1-00001 REV 1... - Page 15 The Limited Warranty does not apply to, and Plugreen will not be responsible for, any defect in or damage to any Plugreen Solar Micro-inverter: (1) that has been misused, neglected, tampered with, altered, or otherwise damaged, either internally or externally; (2) that...
- Page 16 7 Appendix The Limited Warranty is the sole and exclusive warranty given by Plugreen and where permitted by law, is made expressly in lieu of all other warranties, express or implied, statutory or otherwise, including, without limitation, warranties of title, quality, merchantability, fitness for a particular purpose or non-infringement or warranties as to accuracy, sufficiency or suitability of any technical or other information provided in manuals or other documentation.
-
Page 17: Plugreen Installation Map
Copyright Plugreen Corporation. 2011 1-00001 REV 1... - Page 18 Passionately Powered Contact Information Plugreen Corporation, Laattakatu 13, 08150 Lohja, Finland Phone : +358 40 1525086 www.plugreen.com support@plugreen.com...
